Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen™ 3 |
Processor Socket | Socket AM4 |
Maximum number of SMP processors | 1 |
HDCP | Yes |
Maximum Resolution | 5120 x 2880 pixels |
DirectX version | 12.0 |
Overclocking features | FCC, CE
ErP/EuP |
Motherboard chipset family | AMD |
PC health monitoring | Fan |
Audio output channels | 7.1 channels |
MOTHERBOARD CHIPSET | AMD B550 |
Motherboard form factor | micro ATX |
Windows operating systems supported | Windows 10 x64 |
Unbuffered memory | Yes |
Memory channels | Dual-channel |
Supported memory clock speeds | 3466 |
Maximum internal memory | 128 GB |
Supported memory types | DDR4-SDRAM |
Memory slots type | DIMM |
Number of memory slots | 4 |
Width | 244 mm |
Depth | 244 mm |
LAN controller | Realtek RTL8111H |
Wake-on-LAN ready | Yes |
Ethernet LAN | Yes |
Wi-Fi | No |
Ethernet interface type | Gigabit Ethernet |
TPM connector | Yes |
USB 2.0 connectors | 2 |
CPU fan connector | Yes |
Number of chassis fan connectors | 3 |
Number of SATA III connectors | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
Front panel audio connector | Yes |
ATX Power connector (24-pin) | Yes |
12V power connector | Yes |
RGB LED pin header | Yes |
BIOS Type | UEFI AMI |
Drivers included | Yes |
CABLES INCLUDED | SATA |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | Serial ATA III |
HDMI version | 2.1 |
DisplayPorts quantity | 1 |
HDMI ports quantity | 1 |
DisplayPort version | 1.4 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
Ethernet LAN (RJ-45) ports | 1 |
USB 2.0 ports quantity | 2 |
PS/2 ports quantity | 1 |
PCI Express x16 (Gen 3.x) slots | 3 |
Number of M.2 (M) slots | 1 |
PCI Express x1 (Gen 3.x) slots | 1 |
