Compatible processor series | AMD Ryzen™ 7000 Series |
Processor manufacturer | AMD |
Processor Socket | Socket AM5 |
Maximum number of SMP processors | 1 |
audio chip | Realtek ALC897 |
Audio output channels | 7.1 channels |
MOTHERBOARD CHIPSET | AMD B650 |
Motherboard form factor | Mini-ITX |
Windows operating systems supported | Windows 11 x64 |
Motherboard chipset family | AMD |
Unbuffered memory | Yes |
Maximum internal memory | 96 GB |
Memory channels | Dual-channel |
Supported memory types | DDR5-SDRAM |
Memory slots type | DIMM |
Number of memory slots | 2 |
Width | 170 mm |
Depth | 170 mm |
LAN controller | Dragon RTL8125BG |
Bluetooth | Yes |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Ethernet LAN | Yes |
Wi-Fi standards | 802.11a |
Bluetooth Version | 5.2 |
Wi-Fi | Yes |
Ethernet interface type | 2.5 Gigabit Ethernet |
ATX Power connector (24-pin) | Yes |
EPS power connector (8-pin) | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Front panel audio connector | Yes |
Number of SATA III connectors | 2 |
USB 2.0 connectors | 1 |
CPU fan connector | Yes |
USB Type-C socket on the front panel | Y |
RGB LED pin header | Yes |
BIOS Type | UEFI AMI |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
RAID levels | 1 |
Number of storage drives supported | 4 |
Raid Support | Yes |
USB 2.0 ports quantity | 4 |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
BIOS switch button | Yes |
Microphone in | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
HDMI ports quantity | 1 |
Wi-Fi antenna socket | Yes |
Line-in | Yes |
Number of M.2 (M) slots | 1 |
PCI Express x1 (Gen 4.x) slots | 1 |
