Processor Socket | LGA 1700 |
Compatible processor series | Intel® Core™ i5 |
Processor manufacturer | Intel |
Supported processor sockets | LGA 1700 |
Maximum Resolution | 7680 x 4320 pixels |
Certification | FCC, CE, ErP/EuP |
Windows operating systems supported | Windows 10 x64 |
Audio output channels | 7.1 channels |
MOTHERBOARD CHIPSET | Intel B760 |
Motherboard form factor | Mini-ITX |
Product colour | Black |
audio chip | Realtek ALC897 |
Motherboard chipset family | Intel |
Memory channels | Dual-channel |
Supported memory types | DDR5-SDRAM |
Memory slots type | DIMM |
Supported memory clock speed (max) | 8600 MHz |
Number of memory slots | 2 |
Unbuffered memory | Yes |
Maximum internal memory | 96 GB |
Depth | 170 mm |
Width | 170 mm |
Ethernet LAN | Yes |
Wi-Fi standards | Wi-Fi 6E (802.11ax) |
Top Wi-Fi standard | Wi-Fi 6E (802.11axe) |
Bluetooth Version | 5.3 |
Ethernet interface type | 2.5 Gigabit Ethernet |
Wi-Fi | Yes |
LAN controller | Dragon RTL8125BG |
Bluetooth | Yes |
EPS power connector (8-pin) | Yes |
CPU fan connector | Yes |
Number of chassis fan connectors | 2 |
12V power connector | Yes |
USB Type-C socket on the front panel | Y |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Front panel audio connector | Yes |
Number of SATA III connectors | 3 |
ATX Power connector (24-pin) | Yes |
USB 2.0 connectors | 1 |
BIOS Type | UEFI AMI |
CABLES INCLUDED | SATA |
Antenna included | Yes |
Screws included | Yes |
Number of storage drives supported | 5 |
Supported storage drive types | HDD & SSD |
RAID levels | 0 |
Supported storage drive interfaces | M.2, PCI Express 4.0, SATA III |
Raid Support | Yes |
Line-out | Yes |
WiFi-AP antenna jack | 2 |
HDMI ports quantity | 1 |
MIC input | 1 |
Number of USB 3.2 Gen 2 Type-A ports | 1 |
SPDIF optical output | Y |
Ethernet LAN (RJ-45) ports | 1 |
DisplayPort version | 1.4 |
DisplayPorts quantity | 1 |
USB connector type | USB Type-A |
PCI Express x16 (Gen 5.x) slots | 1 |
Number of M.2 (M) slots | 2 |
