Maximum number of SMP processors | 1 |
Processor Socket | LGA 1700 |
Compatible processor series | Intel® Core™ i3 |
Processor manufacturer | Intel |
Parallel processing technology support | Not supported |
Motherboard chipset family | Intel |
audio chip | Realtek ALC897 |
MOTHERBOARD CHIPSET | Intel B760 |
Windows operating systems supported | Windows 10 x64 |
Audio output channels | 7.1 channels |
Motherboard form factor | micro ATX |
Maximum internal memory | 96 GB |
Unbuffered memory | Yes |
Number of memory slots | 2 |
Memory slots type | DIMM |
Supported memory types | DDR5-SDRAM |
Depth | 201 mm |
Width | 244 mm |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
Wi-Fi | Yes (Requires antenna) |
LAN controller | Dragon RTL8125BG |
LED connector | Y |
12V power connector (8-pin) | Y |
USB 2.0 connectors | 2 |
ATX Power connector (24-pin) | Yes |
CPU fan connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Front panel audio connector | Yes |
TPM connector | Yes |
Number of SATA III connectors | 4 |
BIOS Type | UEFI AMI |
Raid Support | Yes |
Supported storage drive interfaces | M.2, SATA III |
Supported storage drive types | HDD & SSD |
RAID levels | 1 |
Number of audio jack connectors | 3 |
WiFi-AP antenna jack | 2 |
Ethernet LAN (RJ-45) ports | 1 |
USB 2.0 ports quantity | 2 |
HDMI ports quantity | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
PCI Express x16 (Gen 4.x) slots | 1 |
Number of M.2 (M) slots | 1 |
PCI Express x1 (Gen 3.x) slots | 2 |
