Compatible processor series | AMD Ryzen 7000 Series |
Processor manufacturer | AMD |
Processor Socket | Socket AM5 |
Windows operating systems supported | Windows 11 x64 |
Audio output channels | 7.1 channels |
Motherboard chipset family | AMD |
MOTHERBOARD CHIPSET | AMD B850 |
Component for | PC |
audio chip | Realtek ALC897 |
Motherboard form factor | ATX |
ECC сompatibility | ECC |
Memory channels | Dual-channel |
Number of memory slots | 4 |
Maximum internal memory | 256 GB |
Memory slots type | DIMM |
Supported memory types | DDR5-SDRAM |
Width | 305 mm |
Depth | 244 mm |
Wi-Fi | Yes |
LAN controller | Dragon RTL8125BG |
Wi-Fi standards | 802.11g |
Ethernet interface type | 2.5 Gigabit Ethernet |
Ethernet LAN | Yes |
Bluetooth | Yes |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Bluetooth Version | 5.2 |
USB 3.2 Gen 2x2 connectors | 1 |
Number of EPS power connectors (8-pin) | 2 |
Number of CPU fan connectors | 2 |
EPS power connector (8-pin) | Yes |
Number of chassis fan connectors | 4 |
USB 2.0 connectors | 2 |
CPU fan connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
Number of SATA III connectors | 4 |
TPM connector | Yes |
Front panel audio connector | Yes |
ATX Power connector (24-pin) | Yes |
RGB LED pin header | Yes |
BIOS memory size | 256 Mbit |
BIOS Type | UEFI AMI |
CABLES INCLUDED | SATA |
Raid Support | Yes |
RAID levels | 0 |
Supported storage drive interfaces | M.2, SATA III |
USB 2.0 ports quantity | 6 |
Microphone in | Yes |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Line-in | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
WiFi-AP antenna jack | 2 |
PCI Express x16 (Gen 5.x) slots | 1 |
Number of M.2 (M) slots | 1 |
PCI Express x16 (Gen 4.x) slots | 1 |
