Supported processor sockets | LGA 1851 |
Compatible processor series | Intel Core Ultra (Series 2) |
Processor Socket | LGA 1851 (Socket V1) |
Processor manufacturer | Intel |
Maximum Resolution | 7680 x 4320 pixels |
On-board graphics card family | Intel Iris Xe Graphics |
HDCP | Yes |
Certification | FCC, CE, ErP/EuP |
audio chip | Realtek ALC1220 |
Motherboard form factor | Mini-ITX |
Product colour | White |
MOTHERBOARD CHIPSET | Intel B860 |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 11 x64 |
Motherboard chipset family | Intel |
Memory slots type | DIMM |
Maximum internal memory | 128 GB |
Memory channels | Dual-channel |
Number of memory slots | 2 |
Supported memory types | DDR5-SDRAM |
Unbuffered memory | Yes |
ECC сompatibility | Non-ECC |
Width | 170 mm |
Depth | 170 mm |
Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
Wi-Fi standards | 802.11b |
Ethernet LAN | Yes |
Top Wi-Fi standard | Wi-Fi 6E (802.11axe) |
MU-MiMO | Yes |
Wi-Fi | Yes |
Ethernet interface type | 2.5 Gigabit Ethernet |
Bluetooth Version | 5.3 |
LAN controller | Dragon RTL8125BG |
Bluetooth | Yes |
USB 2.0 connectors | 2 |
Number of USB 3.2 Gen 2 Type-C ports | 1 |
Number of CPU fan connectors | 1 |
ATX Power connector (24-pin) | Yes |
Number of SATA III connectors | 3 |
Front panel audio connector | Yes |
Number of chassis fan connectors | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
CPU fan connector | Yes |
12V power connector | Yes |
Number of water pump connectors | 1 |
BIOS Type | UEFI AMI |
Supported storage drive types | HDD & SSD |
Raid Support | Yes |
Supported storage drive interfaces | PCI Express 4.0, PCI Express 5.0, SATA III |
RAID levels | 0 |
Number of storage drives supported | 5 |
Ethernet LAN (RJ-45) ports | 1 |
USB connector type | USB Type-A |
Thunderbolt ports quantity | 1 |
Number of USB 3.2 Gen 1 ports | 4 |
S/PDIF out port | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
MIC input | 1 |
HDMI ports quantity | 1 |
USB 2.0 ports quantity | 1 |
Antennas quantity | 2 |
Flashback BIOS button | Yes |
2nd M.2 largest key size | 2280 |
PCI Express x16 (Gen 4.x) slots | 1 |
PCI Express x16 (Gen 5.x) slots | 1 |
2nd M.2 highest PCI Express generation | 4.0 |
1st M.2 largest key size | 2280 |
1st M.2 highest PCI Express generation | 5.0 |
Number of M.2 (M) slots | 4 |
Warnings | Do not open or modify the Motherboard to prevent damage. |
