Processor manufacturer | Intel |
Supported processor sockets | LGA 1851 |
Processor Socket | LGA 1851 (Socket V1) |
Certification | FCC, CE, ErP/EuP |
Motherboard form factor | micro ATX |
Audio output channels | 7.1 channels |
Motherboard chipset family | Intel |
audio chip | Realtek ALC897 |
MOTHERBOARD CHIPSET | Intel B860 |
Windows operating systems supported | Windows 11 x64 |
Unbuffered memory | Yes |
Maximum internal memory | 256 GB |
Memory channels | Dual-channel |
ECC сompatibility | Non-ECC |
Number of memory slots | 4 |
Supported memory types | DDR5-SDRAM |
Memory slots type | DIMM |
Width | 244 mm |
Depth | 244 mm |
Bluetooth | Yes |
Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
LAN controller | Dragon RTL8125BG |
Wi-Fi | Yes |
Ethernet LAN | Yes |
Ethernet interface type | 2.5 Gigabit Ethernet |
USB 2.0 connectors | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
Number of SATA III connectors | 4 |
Number of chassis fan connectors | 3 |
ATX Power connector (24-pin) | Yes |
TPM connector | Yes |
CPU fan connector | Yes |
Number of CPU fan connectors | 2 |
Number of water pump connectors | 1 |
Number of RGB LED pin headers | 1 |
12V power connector | Yes |
RGB LED pin header | Yes |
BIOS Type | UEFI AMI |
Supported storage drive interfaces | M.2, PCI Express 4.0, SATA III |
Raid Support | Yes |
Supported storage drive types | HDD & SSD |
RAID levels | 0 |
USB 2.0 ports quantity | 2 |
HDMI ports quantity | 2 |
HDMI version | 2.1 |
Antennas quantity | 2 |
USB connector type | USB Type-A |
Ethernet LAN (RJ-45) ports | 1 |
Number of USB 3.2 Gen 1 ports | 3 |
Flashback BIOS button | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
Number of M.2 (M) slots | 3 |
PCI Express x16 (Gen 5.x) slots | 1 |
PCI Express x16 (Gen 4.x) slots | 1 |
1st M.2 highest PCI Express generation | 4.0 |
1st M.2 largest key size | 2280 |
