processor | N100 |
processor manufacturer | Intel |
processor socket | NA (integrated CPU) |
Compatible processors | Intel Processor N |
Supported processor slots | BGA 1264 |
number of CPU cores | 4 |
Storage | |
Supported memory | DDR4-SDRAM |
Number of memory slots | 1 |
memory type | DIMM |
ECC-Kompatibilität | Nicht-ECC |
Supported memory clock speed (max.) | 3200 MHz |
RAM memory maximum | 32 GB |
Eigenschaft | Treiber enthalten |
storage controller | |
Supported storage drives | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
Maximum supported number of HDD | 2 |
Number of supported storage drives | 3 |
graphic | |
graphics card family | Intel |
graphic card | Intel® UHD Graphics |
Maximum resolution | 4096 x 2160 Pixel |
Number of displays supported | 3 |
Internal I/O ports | |
Number of USB 2.0 interfaces | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) ports | 1 |
SATA III connectors | 2 |
Number of chassis fan plugs | 2 |
I/O ports on the back | |
Number of USB 2.0 ports | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type-C ports | 1 |
Number of Ethernet LAN ports (RJ-45) | 1 |
Number of PS/2 connections | 1 |
Number of VGA (D-Sub) connections | 1 |
Number of HDMI ports | 1 |
HDMI-Version | 2.1 |
Number of DisplayPort connections | 1 |
DisplayPorts-Version | 1.4 |
headphone outputs | 1 |
network | |
Ethernet interfaces type | Gigabit Ethernet |
LAN-Controller | Realtek 8111H |
features | |
audio chip | Realtek ALC897 |
audio channels | 7.1 Kanäle |
component for | PC |
Motherboardformfaktor | micro ATX |
Motherboard chipset family | Intel |
Supports Windows operating systems | Windows 10 x64, Windows 11 x64 |
certification | - FCC, CE- ErP/EuP ready (ErP/EuP ready power supply is required) |
expansion slots | |
PCI Express x1 (Gen 3.x) connectors | 1 |
PCI Express x16 (Gen 3.x) connectors | 1 |
Number of M.2 (M) slots | 1 |
BIOS | |
BIOS type | UEFI AMI |
BIOS memory size | 128 Mbit |
weight and dimensions | |
broad | 226 mm |
depth | 178 mm |
scope of delivery | |
Supplied cables | SATA |
Included software | - ASRock Motherboard Utility (A-Tuning)- ASRock XFast LAN |
Technical details | |
Konformitätsbescheinigungen | Eidgenössische Kommunikationskommission (FCC) |
