Sustainability certificates | Federal Communications Commission (FCC) |
Sustainability compliance | Yes |
Supported processor sockets | LGA 1700 |
Processor manufacturer | Intel |
Compatible processor series | Intel® Core™ i5 |
Processor Socket | LGA 1700 |
HDCP | Yes |
Graphics card | Intel Iris Xe Graphics |
Maximum Resolution | 7680 x 4320 pixels |
Parallel processing technology support | Crossfire |
Graphics card family | Intel |
Motherboard chipset family | Intel |
Product colour | Black |
audio chip | Realtek ALC4082 |
MOTHERBOARD CHIPSET | Intel Z790 |
Windows operating systems supported | Windows 11 x64 |
Motherboard form factor | ATX |
Audio output channels | 7.1 channels |
Unbuffered memory | Yes |
Maximum internal memory | 192 GB |
Number of memory slots | 4 |
Memory slots type | DIMM |
Supported memory types | DDR5-SDRAM |
Memory channels | Dual-channel |
Supported memory clock speed (max) | 8000 MHz |
Depth | 244 mm |
Width | 305 mm |
Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
Bluetooth | Yes |
LAN controller | Killer E3100G |
Wi-Fi standards | 802.11a |
Bluetooth Version | 5.4 |
Ethernet interface type | 2.5 Gigabit Ethernet |
Wi-Fi | Yes |
Ethernet LAN | Yes |
Number of SATA III connectors | 4 |
Number of chassis fan connectors | 5 |
CPU fan connector | Yes |
ATX Power connector (24-pin) | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
TPM connector | Yes |
USB 2.0 connectors | 2 |
Thunderbolt headers | 1 |
Front panel audio connector | Yes |
12V power connector | Yes |
RGB LED pin header | Yes |
USB 3.2 Gen 2x2 connectors | 1 |
Clear CMOS button | Yes |
BIOS Type | UEFI AMI |
Bundled software | - ASRock Motherboard Utility (Phantom Gaming Tuning)
- Killer Control Center
- ASRock Polychrome SYNC |
CABLES INCLUDED | SATA |
Antenna included | Yes |
Screws included | Yes |
M.2 standoff included | Yes |
Supported storage drive interfaces | M.2 |
RAID levels | 0 |
Raid Support | Yes |
Number of storage drives supported | 6 |
DisplayPort version | 1.4 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
S/PDIF out port | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
Ethernet LAN (RJ-45) ports | 1 |
USB connector type | USB Type-C |
DisplayPorts quantity | 1 |
USB 2.0 ports quantity | 2 |
Microphone in | Yes |
HDMI ports quantity | 1 |
WiFi-AP antenna jack | 2 |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
HDMI version | 2.1 |
Number of M.2 (M) slots | 1 |
PCI Express x1 (Gen 3.x) slots | 1 |
PCI Express x16 (Gen 4.x) slots | 1 |
PCI Express x16 (Gen 5.x) slots | 1 |
