Compatible processor series | Intel® Core™ i7 |
Processor manufacturer | Intel |
Maximum number of SMP processors | 1 |
Processor Socket | LGA 1700 |
audio chip | Realtek ALC897 |
Motherboard form factor | mini ITX |
Windows operating systems supported | Windows 10 x64 |
Audio output channels | 7.1 channels |
MOTHERBOARD CHIPSET | Intel Z790 |
Motherboard chipset family | Intel |
Supported memory types | DDR5-SDRAM |
Memory slots type | DIMM |
Memory channels | Dual-channel |
Maximum internal memory | 64 GB |
Number of memory slots | 2 |
Unbuffered memory | Yes |
Width | 170 mm |
Depth | 170 mm |
Wi-Fi standards | 802.11g |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Ethernet interface type | 2.5 Gigabit Ethernet |
Wi-Fi | Yes |
Bluetooth | Yes |
Ethernet LAN | Yes |
RGB LED pin header | Yes |
USB 2.0 connectors | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Front panel audio connector | Yes |
Number of SATA III connectors | 4 |
ATX Power connector (24-pin) | Yes |
BIOS Type | UEFI AMI |
Raid Support | Yes |
RAID levels | 10 |
Supported storage drive interfaces | M.2, SATA III |
Supported storage drive types | HDD & SSD |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
Line-in | Yes |
DisplayPorts quantity | 1 |
DisplayPort version | 1.4 |
USB 2.0 ports quantity | 1 |
HDMI ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
Headphone outputs | 1 |
S/PDIF out port | Yes |
PCI Express x16 (Gen 5.x) slots | 1 |
