Compatible processor series | Intel Core Ultra (Series 2) |
Processor manufacturer | Intel |
Processor Socket | LGA 1851 (Socket V1) |
Motherboard chipset family | Intel |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 11 x64 |
audio chip | Realtek ALC1220 |
Component for | PC |
MOTHERBOARD CHIPSET | Intel Z890 |
Motherboard form factor | ATX |
Operating system architecture | 64-bit |
Memory channels | Dual-channel |
Maximum internal memory | 256 GB |
Unbuffered memory | Yes |
Memory slots type | DIMM |
Supported memory types | DDR5 non-ECC |
Number of memory slots | 4 |
Supported memory clock speed (max) | 9066 MHz |
LAN controller | Dragon RTL8125BG |
Bluetooth | Yes |
Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
Wi-Fi standards | Wi-Fi 5 (802.11ac) |
Ethernet LAN | Yes |
MU-MiMO | Yes |
Ethernet interface type | 2.5 Gigabit Ethernet |
Wi-Fi | Yes |
Bluetooth Version | 5.4 |
Front panel audio connector | Yes |
Number of SATA III connectors | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 8 |
CPU fan connector | Yes |
ATX Power connector (24-pin) | Yes |
Thunderbolt 4 ports quantity | 2 |
USB 2.0 connectors | 2 |
USB 3.2 Gen 2x2 Type-C ports quantity | 2 |
RGB LED pin header | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 2 |
BIOS memory size | 256 Mbit |
BIOS Type | UEFI AMI |
Supported storage drive interfaces | Blazing M.2 (PCIe Gen5 x4), Hyper M.2 (PCIe Gen4 x4) |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
S/PDIF out port | Yes |
HDMI ports quantity | 1 |
External antenna connector | Yes, x 2 |
Number of USB 3.2 Gen 1 ports | 4 |
Microphone in | Yes |
Line-out | Yes |
PCI Express x16 (Gen 5.x) slots | 1 |
