Processor manufacturer | Intel |
Maximum number of SMP processors | 1 |
Compatible processor series | Intel Core Ultra (Series 2) |
Processor Socket | LGA1851 |
Windows operating systems supported | Windows 10 x64 |
MOTHERBOARD CHIPSET | Intel Z890 |
Audio output channels | 7.1 channels |
Motherboard chipset family | Intel |
Motherboard form factor | ATX |
audio chip | Realtek ALC1220 |
ECC сompatibility | Non-ECC |
Intel Extreme Memory Profile (XMP) version | 3.0 |
Memory slots type | DIMM |
Supported memory types | DDR5-SDRAM |
Number of memory slots | 4 |
Memory channels | Dual-channel |
Maximum internal memory | 256 GB |
Unbuffered memory | Yes |
Depth | 244 mm |
Width | 305 mm |
Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
Wi-Fi standards | IEEE 802.11a |
Wi-Fi | Yes |
Wi-Fi frequency | 2,4 Ghz / 5 GHz / 6 GHz |
Ethernet LAN | Yes |
Ethernet interface type | 2.5 Gigabit Ethernet |
Wireless statistics | Yes |
LAN controller | Killer E3100G |
8-pin power connector 12 V | 2 |
Chassis fan connector (4-pin) | 4 |
Number of USB 3.2 Gen 2x2 (3.1 Gen 2x2) Type-C ports | 1 |
AIO pump fan connector | 1 |
Pump connector | 1 |
TPM connector | Yes |
RGB LED pin header | Yes |
Number of SATA III connectors | 4 |
Thunderbolt headers | 1 |
Front panel audio connector | Yes |
ATX Power connector (24-pin) | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
USB 2.0 connectors | 2 |
CPU fan connector | 2 |
BIOS Type | UEFI AMI |
Motherboard | Yes |
Antennas quantity | 2 |
Wi-Fi Antenna | Yes |
CABLES INCLUDED | SATA III 2 pcs. |
RAID levels | 0 |
Supported storage drive types | HDD & SSD |
Raid Support | Yes |
Supported storage drive interfaces | M.2, SATA III |
SPDIF optical output | Y |
Number of Thunderbolt 4 USB-C ports | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
USB 2.0 Type-A ports quantity | 2 |
Microphone in | Yes |
Headphone outputs | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
HDMI ports quantity | 1 |
Number of antenna connectors | 2 |
Ethernet LAN (RJ-45) ports | 1 |
PCI Express x16 (Gen 4.x) slots | 1 |
PCI Express x16 (Gen 5.x) slots | 1 |
PCI Express x1 (Gen 3.x) slots | 1 |
Number of M.2 (M) slots | 1 |
Certificates | FCC |
