Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen™ 3 |
Supported processor sockets | Socket AM4 |
Processor Socket | Socket AM4 |
Parallel processing technology support | Not supported |
Motherboard form factor | micro ATX |
Windows operating systems supported | Windows 10 x64 |
Audio output channels | 7.1 channels |
Component for | PC |
audio chip | Realtek ALC887 / Realtek ALC897 |
Motherboard chipset family | AMD |
MOTHERBOARD CHIPSET | AMD A520 |
Memory slots type | DIMM |
Supported memory clock speeds | 2133 |
Memory channels | Dual-channel |
Number of memory slots | 2 |
Supported memory types | DDR4-SDRAM |
Unbuffered memory | Yes |
Maximum internal memory | 64 GB |
ECC сompatibility | ECC |
Depth | 221 mm |
Width | 226 mm |
Wake-on-LAN ready | Yes |
LAN controller | Realtek RTL8111H |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
Wi-Fi | No |
Number of chassis fan connectors | 1 |
ATX Power connector (24-pin) | Yes |
Number of SATA III connectors | 4 |
USB 2.0 connectors | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
TPM connector | Yes |
Front panel audio connector | Yes |
S/PDIF out connector | Yes |
12V power connector | Yes |
Number of COM connectors | 1 |
CPU fan connector | Yes |
Number of EATX power connectors | 2 |
BIOS Type | UEFI AMI |
BIOS memory size | 256 Mbit |
Clear CMOS jumper | Yes |
CABLES INCLUDED | SATA |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
Raid Support | Yes |
RAID levels | 0 |
Number of storage drives supported | 5 |
VGA (D-Sub) ports quantity | 1 |
USB connector type | USB Type-A |
USB 2.0 ports quantity | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
Headphone outputs | 3 |
HDMI version | 2.1 |
HDMI ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
PS/2 ports quantity | 1 |
Microphone in | Yes |
Number of M.2 (M) slots | 1 |
PCI Express x16 (Gen 3.x) slots | 1 |
PCI Express x1 (Gen 3.x) slots | 2 |
Harmonized System (HS) code | 84733020 |
