Supported processor sockets | Socket AM5 |
Processor Socket | Socket AM5 |
Compatible processor series | AMD Ryzen 5 7th Gen |
Processor manufacturer | AMD |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 10 x64 |
Motherboard chipset family | AMD |
Motherboard form factor | micro ATX |
MOTHERBOARD CHIPSET | AMD A620 |
ECC сompatibility | Non-ECC |
Supported memory clock speeds | 6000 |
Maximum internal memory | 96 GB |
Unbuffered memory | Yes |
Memory channels | Dual-channel |
Number of memory slots | 2 |
Supported memory types | DDR5-SDRAM |
Depth | 221 mm |
Width | 226 mm |
Ethernet LAN | Yes |
Wi-Fi | No |
Ethernet interface type | Gigabit Ethernet |
ATX Power connector (24-pin) | Yes |
CPU fan connector | Yes |
Number of chassis fan connectors | 1 |
USB 2.0 connectors | 2 |
EPS power connector (8-pin) | Yes |
Front panel audio connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Number of SATA III connectors | 4 |
Number of COM connectors | 1 |
S/PDIF out connector | Yes |
12V power connector | Yes |
TPM connector | Yes |
BIOS Type | UEFI AMI |
PACKAGE WEIGHT | 920 g |
Package width | 260 mm |
Package height | 51.5 mm |
Package depth | 270 mm |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
Number of HDDs supported | 4 |
Number of storage drives supported | 5 |
USB 2.0 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
VGA (D-Sub) ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
PS/2 ports quantity | 1 |
HDMI ports quantity | 1 |
Number of M.2 (M) slots | 1 |
PCI Express x1 (Gen 3.x) slots | 1 |
