Supported processor sockets | Socket AM5 |
Compatible processor series | AMD Ryzen 9 7th Gen |
Processor manufacturer | AMD |
Processor Socket | Socket AM5 |
Windows operating systems supported | Windows 10 x64 |
Motherboard form factor | micro ATX |
Audio output channels | 7.1 channels |
MOTHERBOARD CHIPSET | AMD B650 |
Motherboard chipset family | AMD |
Memory channels | Dual-channel |
Number of memory slots | 4 |
Memory slots type | DIMM |
Supported memory types | DDR5-SDRAM |
Supported memory clock speeds | 5800 |
Maximum internal memory | 128 GB |
Unbuffered memory | Yes |
Depth | 244 mm |
Height | 50 mm |
Width | 244 mm |
Wi-Fi | Yes |
Ethernet interface type | Gigabit Ethernet |
Bluetooth Version | 5.2 |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
Wi-Fi standards | Wi-Fi 5 (802.11ac) |
Ethernet LAN | Yes |
Bluetooth | Yes |
Front panel audio connector | Yes |
RGB LED pin header | Yes |
Number of chassis fan connectors | 3 |
EPS power connector (8-pin) | Yes |
Number of COM connectors | 1 |
ATX Power connector (24-pin) | Yes |
TPM connector | Yes |
CPU fan connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
Number of SATA III connectors | 4 |
S/PDIF out connector | Yes |
USB 2.0 connectors | 2 |
BIOS Type | UEFI AMI |
Package width | 280 mm |
Package height | 71 mm |
PACKAGE WEIGHT | 1.34 kg |
Package depth | 265 mm |
Number of storage drives supported | 6 |
RAID levels | 1 |
Raid Support | Yes |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
USB 2.0 ports quantity | 4 |
PS/2 ports quantity | 1 |
VGA (D-Sub) ports quantity | 1 |
Microphone in | Yes |
Line-in | Yes |
Ethernet LAN (RJ-45) ports | 1 |
HDMI ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
DisplayPorts quantity | 1 |
Number of M.2 (M) slots | 2 |
PCI Express x16 (Gen 4.x) slots | 3 |
Weight | 700 g |
