Processor Socket | LGA 1700 |
Processor manufacturer | Intel |
Compatible processor series | Intel® Pentium® |
Maximum number of SMP processors | 1 |
MOTHERBOARD CHIPSET | Intel H610 |
Motherboard chipset family | Intel |
Motherboard form factor | micro ATX |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 11 x64 |
Supported memory clock speeds | 2400 |
Maximum internal memory | 64 GB |
Unbuffered memory | Yes |
Memory slots type | DIMM |
Supported memory types | DDR4-SDRAM, LPDDR3-SDRAM |
Memory channels | Dual-channel |
Number of memory slots | 2 |
Depth | 211 mm |
Height | 221 mm |
Width | 244 mm |
Wake-on-LAN ready | Yes |
Ethernet LAN | Yes |
Wi-Fi | No |
Ethernet interface type | Gigabit Ethernet |
S/PDIF out connector | Yes |
Number of chassis fan connectors | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
CPU fan connector | Yes |
TPM connector | Yes |
Front panel audio connector | Yes |
ATX Power connector (24-pin) | Yes |
Number of COM connectors | 1 |
Number of SATA III connectors | 4 |
USB 2.0 connectors | 1 |
12V power connector | Yes |
RGB LED pin header | Yes |
BIOS Type | UEFI AMI |
CABLES INCLUDED | SATA |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
DisplayPorts quantity | 1 |
USB 2.0 ports quantity | 4 |
DisplayPort version | 1.4 |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
HDMI version | 2.1 |
VGA (D-Sub) ports quantity | 1 |
PS/2 ports quantity | 2 |
HDMI ports quantity | 1 |
PCI Express x1 (Gen 3.x) slots | 1 |
Number of M.2 (M) slots | 2 |
PCI Express x16 (Gen 4.x) slots | 1 |
Weight | 382 g |
Harmonized System (HS) code | 84733020 |
