Processor Socket | LGA 1700 |
Maximum number of SMP processors | 1 |
Compatible processor series | Intel® Core™ i5 |
Processor manufacturer | Intel |
Number of displays supported | 2 |
Motherboard form factor | micro ATX |
MOTHERBOARD CHIPSET | Intel H610 |
Motherboard chipset family | Intel |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 11 x64 |
Harmonized System (HS) code | 84733020 |
Unbuffered memory | Yes |
Supported memory clock speeds | 3000 |
Maximum internal memory | 64 GB |
Supported memory types | DDR4-SDRAM |
Number of memory slots | 2 |
Memory slots type | DIMM |
Memory channels | Dual-channel |
Depth | 203 mm |
Width | 234 mm |
Height | 51 mm |
Ethernet LAN | Yes |
Wi-Fi | No |
Ethernet interface type | Gigabit Ethernet |
ATX Power connector (24-pin) | Yes |
USB 2.0 connectors | 1 |
S/PDIF out connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Front panel audio connector | Yes |
Number of SATA III connectors | 4 |
Number of COM connectors | 1 |
12V power connector | Yes |
Number of chassis fan connectors | 1 |
TPM connector | Yes |
CPU fan connector | Yes |
RGB LED pin header | Yes |
EPS power connector (8-pin) | Yes |
BIOS Type | UEFI AMI |
CABLES INCLUDED | SATA |
Drivers included | Yes |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA |
USB 2.0 ports quantity | 4 |
Ethernet LAN (RJ-45) ports | 1 |
VGA (D-Sub) ports quantity | 1 |
PS/2 ports quantity | 1 |
Microphone in | Yes |
HDMI version | 2.1 |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Headphone outputs | 1 |
Number of M.2 (M) slots | 1 |
PCI Express x16 (Gen 3.x) slots | 1 |
PCI Express x16 (Gen 4.x) slots | 1 |
Weight | 842 g |
