Supported processor sockets | LGA 1700 |
Compatible processor series | Intel® Core™ i5 |
Processor manufacturer | Intel |
Processor Socket | LGA 1700 |
Parallel processing technology support | Not supported |
On-board graphics card | No |
Product colour | Black |
Audio output channels | 7.1 channels |
Motherboard chipset family | Intel |
Windows operating systems supported | Windows 11 |
Motherboard form factor | ATX |
Power source type | ATX |
MOTHERBOARD CHIPSET | Intel Z790 |
Supported memory clock speeds | 5000 |
Unbuffered memory | Yes |
Maximum internal memory | 128 GB |
Memory channels | Dual-channel |
Supported memory clock speed (max) | 7200 MHz |
Memory slots type | DIMM |
Number of memory slots | 4 |
Supported memory types | DDR5-SDRAM |
Depth | 234 mm |
Width | 305 mm |
Height | 40 mm |
Bluetooth | Yes |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
Wi-Fi standards | Wi-Fi 5 (802.11ac) |
Wi-Fi | Yes |
Ethernet LAN | Yes |
Ethernet interface type | 2.5 Gigabit Ethernet |
Bluetooth Version | 5.2 |
TPM connector | Yes |
USB 2.0 connectors | 2 |
Thunderbolt headers | 1 |
Front panel audio connector | Yes |
ATX Power connector (24-pin) | Yes |
Number of COM connectors | 1 |
Number of SATA III connectors | 4 |
Peripheral (Molex) power connectors (4-pin) | 1 |
CPU fan connector | Yes |
EPS power connector (8-pin) | Yes |
S/PDIF out connector | Yes |
Number of chassis fan connectors | 3 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
RGB LED pin header | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
12V power connector | Yes |
Clear CMOS button | Yes |
BIOS Type | UEFI AMI |
PACKAGE WEIGHT | 1.68 kg |
Package depth | 273 mm |
Package width | 338 mm |
Package height | 68 mm |
Drivers included | Yes |
CABLES INCLUDED | SATA |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
RAID levels | 5 |
Raid Support | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
DisplayPorts quantity | 1 |
HDMI ports quantity | 1 |
USB 2.0 ports quantity | 4 |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
Microphone in | Yes |
WiFi-AP antenna jack | 1 |
PS/2 ports quantity | 1 |
Headphone outputs | 1 |
Line-in | Yes |
Number of M.2 (M) slots | 3 |
PCI Express x1 (Gen 3.x) slots | 1 |
PCI Express x16 (Gen 4.x) slots | 3 |
PCI Express x16 (Gen 5.x) slots | 1 |
Weight | 1.03 kg |
