Processor manufacturer | AMD |
Supported processor sockets | Socket AM5 |
Processor Socket | Socket AM5 |
Parallel processing technology support | Not supported |
Windows operating systems supported | Windows 11 |
audio chip | Realtek ALC4082 |
Motherboard form factor | ATX |
Audio output channels | 7.1 channels |
Motherboard chipset family | AMD |
MOTHERBOARD CHIPSET | AMD X870E |
Number of memory slots | 4 |
Memory slots type | DIMM |
Memory channels | Dual-channel |
Supported memory types | DDR5-SDRAM |
Maximum internal memory | 192 GB |
Unbuffered memory | Yes |
Height | 50 mm |
Depth | 244 mm |
Width | 305 mm |
Bluetooth | Yes |
Bluetooth Version | 5.4 |
Wi-Fi standards | Wi-Fi 7 (802.11be) |
Ethernet interface type | 5 Gigabit Ethernet |
Wi-Fi | Yes |
Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
Ethernet LAN | Yes |
USB 2.0 connectors | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
EPS power connector (8-pin) | Yes |
ATX Power connector (24-pin) | Yes |
Number of chassis fan connectors | 4 |
12V power connector | Yes |
CPU fan connector | Yes |
Front panel audio connector | Yes |
Number of SATA III connectors | 4 |
USB 3.2 Gen 2x2 connectors | 2 |
Clear CMOS button | Yes |
BIOS Type | UEFI AMI |
PACKAGE WEIGHT | 4.26 kg |
Package width | 370 mm |
Package depth | 312 mm |
Package height | 108 mm |
CABLES INCLUDED | SATA |
Drivers included | Yes |
Supported storage drive interfaces | M.2, SATA III, SlimSAS |
RAID levels | 10 |
Number of HDDs supported | 5 |
Raid Support | Yes |
Supported storage drive types | HDD & SSD |
Number of storage drives supported | 10 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 6 |
Headphone outputs | 1 |
WiFi-AP antenna jack | 1 |
HDMI ports quantity | 1 |
Microphone in | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
S/PDIF out port | Yes |
Ethernet LAN (RJ-45) ports | 2 |
USB4 Gen 2x2 ports quantity | 2 |
PCI Express x16 (Gen 4.x) slots | 4 |
Number of M.2 (M) slots | 5 |
PCI Express x16 (Gen 5.x) slots | 2 |
Weight | 2.55 kg |
