Compatible processor series | AMD Ryzen 3000 Series |
Processor manufacturer | AMD |
Supported processor sockets | Socket AM4 |
Processor Socket | Socket AM4 |
Maximum number of SMP processors | 1 |
Parallel processing technology support | Not supported |
On-board graphics card | No |
Power source type | ATX |
Motherboard chipset family | AMD |
Motherboard form factor | ATX |
MOTHERBOARD CHIPSET | AMD B550 |
Product colour | Black |
Audio output channels | 7.1 channels |
Cooling type | Active |
Windows operating systems supported | Windows 10 Pro |
Supported memory clock speeds | 3000 |
Maximum internal memory | 128 GB |
Supported memory types | DDR4-SDRAM |
Memory slots type | DIMM |
Number of memory slots | 4 |
ECC сompatibility | ECC |
Depth | 244 mm |
Width | 305 mm |
Height | 68 mm |
LAN controller | Intel I225-V |
Wake-on-LAN ready | Yes |
Bluetooth | Yes |
Wi-Fi standards | Wi-Fi 5 (802.11ac) |
Ethernet LAN | Yes |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
Ethernet interface type | 2.5 Gigabit Ethernet |
Bluetooth Version | 5.2 |
Wi-Fi | Yes |
USB 2.0 connectors | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Thunderbolt headers | 1 |
Number of SATA III connectors | 6 |
CPU fan connector | Yes |
Number of chassis fan connectors | 3 |
Peripheral (Molex) power connectors (4-pin) | 1 |
Number of EATX power connectors | 1 |
12V power connector | Yes |
RGB LED pin header | Yes |
EPS power connector (8-pin) | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
BIOS Type | UEFI AMI |
CABLES INCLUDED | SATA |
Drivers included | Yes |
Supported storage drive types | HDD & SSD |
RAID levels | 0 |
Raid Support | Yes |
Supported storage drive interfaces | M.2, SATA III |
Number of HDDs supported | 6 |
USB 2.0 ports quantity | 2 |
DisplayPorts quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
DisplayPort version | 1.2 |
S/PDIF out port | Yes |
HDMI version | 2.1 |
Microphone in | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
HDMI ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Headphone outputs | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
Number of M.2 (M) slots | 2 |
PCI Express x1 (Gen 3.x) slots | 3 |
PCI Express x16 (Gen 3.x) slots | 1 |
PCI Express x16 (Gen 4.x) slots | 1 |
Weight | 945 g |
Harmonized System (HS) code | 84733020 |
