Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen™ 7 |
Supported processor sockets | Socket AM5 |
Processor Socket | Socket AM5 |
Parallel processing technology support | Not supported |
On-board graphics card | No |
MOTHERBOARD CHIPSET | AMD B650 |
audio chip | Realtek ALC4080 |
Product colour | Black |
Motherboard chipset family | AMD |
Windows operating systems supported | Windows 11 x64 |
Audio output channels | 7.1 channels |
Motherboard form factor | mini ITX |
Supported memory clock speeds | 6000 |
Unbuffered memory | Yes |
Maximum internal memory | 64 GB |
Memory slots type | DIMM |
Memory channels | Dual-channel |
ECC сompatibility | ECC & Non-ECC |
Supported memory types | DDR5-SDRAM |
Number of memory slots | 2 |
Width | 170 mm |
Depth | 170 mm |
Bluetooth | Yes |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Wi-Fi standards | Wi-Fi 5 (802.11ac) |
Ethernet interface type | 2.5 Gigabit Ethernet |
Wi-Fi | Yes |
Bluetooth Version | 5.2 |
Ethernet LAN | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
CPU fan connector | Yes |
Number of SATA III connectors | 2 |
EPS power connector (8-pin) | Yes |
Audio connector | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
USB 2.0 connectors | 2 |
Front panel audio connector | Yes |
ATX Power connector (24-pin) | Yes |
12V power connector | Yes |
RGB LED pin header | Yes |
Number of chassis fan connectors | 1 |
BIOS Type | UEFI AMI |
Clear CMOS button | Yes |
PACKAGE WEIGHT | 8.58 kg |
Package width | 222 mm |
Package depth | 182 mm |
Package height | 92 mm |
CABLES INCLUDED | SATA, USB |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
RAID levels | 0 |
Raid Support | Yes |
HDMI ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
USB 2.0 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
S/PDIF out port | Yes |
Line-in | Yes |
Headphone outputs | 1 |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
Microphone in | Yes |
Number of M.2 (M) slots | 2 |
PCI Express x16 (Gen 5.x) slots | 1 |
