Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen 7 8th Gen |
Processor Socket | Socket AM5 |
Parallel processing technology support | Not supported |
Product colour | Black |
Audio output channels | 7.1 channels |
Motherboard chipset family | AMD |
MOTHERBOARD CHIPSET | AMD X870 |
Windows operating systems supported | Windows 11 |
Motherboard form factor | ATX |
Unbuffered memory | Yes |
Memory channels | Dual-channel |
Maximum internal memory | 192 GB |
Number of memory slots | 4 |
Memory slots type | DIMM |
Supported memory types | DDR5-SDRAM |
Supported memory clock speed (max) | 8000 MHz |
Depth | 244 mm |
Width | 305 mm |
Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
Bluetooth | Yes |
Wi-Fi standards | Wi-Fi 7 (802.11be) |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Wi-Fi | Yes |
Bluetooth Version | 5.4 |
CPU fan connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
Chassis intrusion connector | Yes |
Number of chassis fan connectors | 5 |
Number of SATA III connectors | 2 |
EPS power connector (8-pin) | Yes |
Front panel audio connector | Yes |
USB 2.0 connectors | 2 |
ATX Power connector (24-pin) | Yes |
USB 3.2 Gen 2x2 connectors | 1 |
BIOS Type | UEFI AMI |
Clear CMOS button | Yes |
Supported storage drive types | HDD & SSD |
RAID levels | 5 |
Raid Support | Yes |
Supported storage drive interfaces | M.2, SATA III |
Number of storage drives supported | 6 |
Number of HDDs supported | 2 |
DisplayPorts quantity | 1 |
S/PDIF out port | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 5 |
Ethernet LAN (RJ-45) ports | 1 |
HDMI ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Microphone in | Yes |
USB4 Gen 3x2 ports quantity | 2 |
Number of M.2 (M) slots | 4 |
PCI Express x16 (Gen 4.x) slots | 1 |
