Processor manufacturer | Intel |
Compatible processor series | Intel Core Ultra (Series 2) |
Processor Socket | LGA 1851 (Socket V1) |
On-board graphics card | No |
Parallel processing technology support | Not supported |
Windows operating systems supported | Windows 11 |
MOTHERBOARD CHIPSET | Intel Z890 |
Audio output channels | 7.1 channels |
Motherboard form factor | ATX |
audio chip | Realtek ALC4080 |
Motherboard chipset family | Intel |
Product colour | Black |
ECC сompatibility | Non-ECC |
Memory channels | Dual-channel |
Memory slots type | DIMM |
Supported memory types | DDR5-SDRAM |
Number of memory slots | 4 |
Supported memory clock speed (max) | 8800 MHz |
Unbuffered memory | Yes |
Maximum internal memory | 192 GB |
Depth | 244 mm |
Width | 305 mm |
Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
Bluetooth Version | 5.4 |
Ethernet LAN | Yes |
Wi-Fi | Yes |
Ethernet interface type | 5 Gigabit Ethernet |
Bluetooth | Yes |
USB 3.2 Gen 2x2 connectors | 1 |
EPS power connector (8-pin) | Yes |
CPU fan connector | Yes |
Chassis intrusion connector | Yes |
12V power connector | Yes |
Number of chassis fan connectors | 5 |
USB 2.0 connectors | 3 |
Thunderbolt headers | 1 |
Front panel audio connector | Yes |
Number of SATA III connectors | 4 |
ATX Power connector (24-pin) | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
Clear CMOS button | Yes |
BIOS Type | UEFI AMI |
Package depth | 87 mm |
Package width | 356 mm |
Package height | 281 mm |
PACKAGE WEIGHT | 2.58 kg |
Number of storage drives supported | 11 |
Number of HDDs supported | 4 |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
RAID levels | 5 |
Raid Support | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 7 |
Microphone in | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
Thunderbolt ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
HDMI ports quantity | 1 |
USB connector type | USB Type-A |
Ethernet LAN (RJ-45) ports | 1 |
DisplayPorts quantity | 1 |
S/PDIF out port | Yes |
PCI Express x16 (Gen 4.x) slots | 1 |
Number of M.2 (M) slots | 7 |
PCI Express x16 (Gen 5.x) slots | 1 |
