Compatible processor series | Intel® Core™ i5 |
Processor manufacturer | Intel |
Maximum number of SMP processors | 1 |
Processor Socket | LGA 1700 |
Supported processor sockets | LGA 1700 |
On-board graphics card | No |
Parallel processing technology support | Not supported |
Product colour | Black |
Windows operating systems supported | Windows 10 |
Audio output channels | 7.1 channels |
Motherboard chipset family | Intel |
Motherboard form factor | ATX |
Cooling type | Passive |
MOTHERBOARD CHIPSET | Intel B760 |
Power source type | ATX |
Number of memory slots | 4 |
Supported memory types | DDR4-SDRAM |
Memory slots type | DIMM |
Memory channels | Dual-channel |
Maximum internal memory | 192 GB |
Unbuffered memory | Yes |
Width | 305 mm |
Depth | 244 mm |
Wi-Fi | Yes |
Bluetooth Version | 5.2 |
Ethernet interface type | 2.5 Gigabit Ethernet |
Wi-Fi standards | Wi-Fi 5 (802.11ac) |
Ethernet LAN | Yes |
Bluetooth | Yes |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
12V power connector | Yes |
RGB LED pin header | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
EPS power connector (8-pin) | Yes |
CPU fan connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
ATX Power connector (24-pin) | Yes |
Front panel connector | Yes |
Number of SATA III connectors | 4 |
Front panel audio connector | Yes |
Number of COM connectors | 1 |
Thunderbolt headers | 1 |
Peripheral (Molex) power connectors (4-pin) | 1 |
Number of chassis fan connectors | 4 |
USB 2.0 connectors | 2 |
BIOS Type | UEFI AMI |
Package depth | 76 mm |
PACKAGE WEIGHT | 1.98 kg |
Package width | 331 mm |
Package height | 266 mm |
User guide | Yes |
CABLES INCLUDED | SATA |
Number of storage drives supported | 7 |
Number of HDDs supported | 4 |
RAID levels | 1 |
Raid Support | Yes |
Supported storage drive interfaces | M.2, SATA III |
Supported storage drive types | HDD & SSD |
Line-in | Yes |
Headphone outputs | 1 |
Microphone in | Yes |
WiFi-AP antenna jack | 2 |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
USB 2.0 ports quantity | 1 |
HDMI ports quantity | 1 |
S/PDIF out port | Yes |
DisplayPort version | 1.4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
DisplayPorts quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
Ethernet LAN (RJ-45) ports | 1 |
HDMI version | 2.1 |
PCI Express x16 (Gen 5.x) slots | 1 |
Number of M.2 (M) slots | 3 |
PCI Express x1 (Gen 3.x) slots | 2 |
PCI Express x16 (Gen 3.x) slots | 1 |
