Supported processor sockets | Socket AM5 |
Processor Socket | Socket AM5 |
Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen 9000 Series |
Parallel processing technology support | Not supported |
Motherboard form factor | micro ATX |
MOTHERBOARD CHIPSET | AMD B850 |
Motherboard chipset family | AMD |
Audio output channels | 7.1 channels |
audio chip | Realtek ALC1220P |
Windows operating systems supported | Windows 10 x64 |
Unbuffered memory | Yes |
Maximum internal memory | 192 GB |
Number of memory slots | 4 |
Supported memory types | DDR5-SDRAM |
Memory slots type | DIMM |
Memory channels | Dual-channel |
ECC сompatibility | ECC & Non-ECC |
Depth | 244 mm |
Width | 244 mm |
Wi-Fi | No |
Ethernet interface type | 2.5 Gigabit Ethernet |
Ethernet LAN | Yes |
S/PDIF out connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Front panel audio connector | Yes |
Number of SATA III connectors | 4 |
CPU fan connector | Yes |
USB 2.0 connectors | 2 |
Number of chassis fan connectors | 3 |
12V power connector | Yes |
Front panel connector | Yes |
ATX Power connector (24-pin) | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
Number of COM connectors | 1 |
Chassis intrusion connector | Yes |
BIOS Type | UEFI AMI |
PACKAGE WEIGHT | 1.65 kg |
Package height | 67.5 mm |
Package width | 275 mm |
Package depth | 275 mm |
CABLES INCLUDED | SATA |
Screws included | Yes |
RAID levels | 5 |
Raid Support | Yes |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
Number of storage drives supported | 7 |
Number of HDDs supported | 4 |
DisplayPorts quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
USB 2.0 ports quantity | 4 |
WiFi-AP antenna jack | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
HDMI ports quantity | 1 |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
Number of M.2 (M) slots | 3 |
PCI Express x16 (Gen 4.x) slots | 1 |
3rd M.2 highest PCI Express generation | 4.0 |
2nd M.2 largest key size | 2280 |
2nd M.2 highest PCI Express generation | 4.0 |
PCI Express x1 (Gen 4.x) slots | 1 |
1st M.2 largest key size | 2280 |
PCI Express x16 (Gen 5.x) slots | 1 |
3rd M.2 largest key size | 2280 |
1st M.2 highest PCI Express generation | 5.0 |
Weight | 1.19 kg |
Warnings | Do not disassemble to avoid damage to internal components and loss of warranty. |
