Supported processor sockets | Socket AM5 |
Compatible processor series | AMD Ryzen™ 7 |
Processor manufacturer | AMD |
Processor Socket | Socket AM5 |
HDCP | Yes |
Maximum Resolution | 4096 x 2160 pixels |
DirectX version | 12.0 |
Motherboard chipset family | AMD |
Motherboard form factor | micro ATX |
PC health monitoring | CPU |
Product colour | Black |
audio chip | Realtek ALC897 |
Audio output channels | 7.1 channels |
MOTHERBOARD CHIPSET | AMD B650 |
Windows operating systems supported | Windows 10 x64 |
Supported memory clock speeds | 5600 |
Maximum internal memory | 96 GB |
Supported memory module capacities | 48GB |
Memory channels | Dual-channel |
ECC сompatibility | Non-ECC |
Supported memory types | DDR5-SDRAM |
Memory slots type | DIMM |
Number of memory slots | 2 |
Depth | 235 mm |
Width | 221 mm |
LAN controller | Realtek RTL8111H |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
Front panel audio connector | Yes |
CPU fan connector | Yes |
Number of chassis fan connectors | 1 |
ATX Power connector (24-pin) | Yes |
Number of SATA III connectors | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
TPM connector | Yes |
Number of COM connectors | 1 |
USB 2.0 connectors | 2 |
Front panel connector | Yes |
12V power connector | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
Audio connector | Yes |
Clear CMOS jumper | Yes |
Bundled software | BullGuard |
CABLES INCLUDED | SATA |
Drivers included | Yes |
Raid Support | Yes |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, PCI Express 4.0, SATA III |
RAID levels | 1 |
DisplayPort version | 1.2 |
DisplayPorts quantity | 1 |
USB 2.0 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
HDMI ports quantity | 1 |
HDMI version | 1.4 |
Number of M.2 (M) slots | 1 |
PCI Express x1 (Gen 3.x) slots | 1 |
PCI Express x16 (Gen 4.x) slots | 1 |
