Processor Socket | Socket AM4 |
Compatible processor series | 3rd Generation AMD Ryzen™ 3 |
Processor manufacturer | AMD |
Supported processor sockets | Socket AM4 |
HDCP | Yes |
Maximum Resolution | 4096 x 2160 pixels |
Motherboard form factor | ATX |
MOTHERBOARD CHIPSET | AMD A520 |
Audio output channels | 7.1 channels |
PC health monitoring | Temperature |
audio chip | Realtek ALC1200 |
Motherboard chipset family | AMD |
Windows operating systems supported | Windows 10 x64 |
Supported memory clock speeds | 4600 |
Maximum internal memory | 128 GB |
Unbuffered memory | Yes |
Memory channels | Dual-channel |
Number of memory slots | 4 |
Supported memory types | DDR4-SDRAM |
Memory slots type | DIMM |
Depth | 244 mm |
Width | 305 mm |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
USB 2.0 connectors | 2 |
Power fan connector | Yes |
Number of SATA III connectors | 4 |
TPM connector | Yes |
CPU fan connector | Yes |
Front panel audio connector | Yes |
EPS power connector (8-pin) | Yes |
Front panel connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Serial port headers | 1 |
ATX Power connector (24-pin) | Yes |
RGB LED pin header | Yes |
Clear CMOS jumper | Yes |
BIOS Type | UEFI AMI |
Desktop Management Interface (DMI) version | 2.7 |
Supported storage drive interfaces | M.2, Serial ATA III |
RAID levels | 10 |
Number of storage drives supported | 5 |
S/PDIF out port | Yes |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
HDMI version | 2.1 |
DVI-D ports quantity | 1 |
USB 2.0 ports quantity | 4 |
PS/2 ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
HDMI ports quantity | 1 |
Headphone outputs | 5 |
PCI Express x16 slots | 1 |
Number of M.2 (M) slots | 1 |
PCI Express x1 slots | 3 |
