Warranty period | 3 year(s) |
Supported processor sockets | Socket AM4 |
Compatible processor series | 3rd Generation AMD Ryzen 5 |
Maximum internal memory supported by processor | 64 GB |
Processor manufacturer | AMD |
Processor Socket | Socket AM4 |
Maximum Resolution | 5120 x 2880 pixels |
DirectX version | 12.0 |
HDCP | Yes |
Parallel processing technology support | Not supported |
Number of displays supported | 3 |
Product colour | Black |
Motherboard chipset family | AMD |
Audio output channels | 7.1 channels |
PC health monitoring | Temperature |
Motherboard form factor | mini ITX |
audio chip | Realtek ALC887 |
MOTHERBOARD CHIPSET | AMD A520 |
Windows operating systems supported | Windows 10 x64 |
Supported memory clock speeds | 4000 |
Maximum internal memory | 64 GB |
Supported memory module capacities | 2GB |
Unbuffered memory | Yes |
Memory channels | Dual-channel |
Memory slots type | DIMM |
Supported memory types | DDR4-SDRAM |
Number of memory slots | 2 |
Supported memory clock speed (max) | 5300 MHz |
Height | 35 mm |
Depth | 170 mm |
Width | 170 mm |
Bluetooth | Yes |
Wi-Fi standards | 802.11a |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Bluetooth Version | 4.2 |
Ethernet interface type | Gigabit Ethernet |
Ethernet LAN | Yes |
Wi-Fi | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
USB 2.0 connectors | 1 |
Serial port headers | 1 |
CPU fan connector | Yes |
ATX Power connector (24-pin) | Yes |
TPM connector | Yes |
Front panel connector | Yes |
EPS power connector (8-pin) | Yes |
Number of SATA III connectors | 4 |
Power fan connector | Yes |
Total number of SATA connectors | 4 |
Front panel audio connector | Yes |
Audio connector | Yes |
RGB LED pin header | Yes |
Clear CMOS jumper | Yes |
BIOS Type | UEFI AMI |
Desktop Management Interface (DMI) version | 2.7 |
Bundled software | Norton® Internet Security (OEM version), Realtek® 8118 Gaming LAN Bandwidth Control Utility |
Batteries Included | Yes |
Supported storage drive interfaces | M.2, SATA III |
RAID levels | 10 |
Number of storage drives supported | 5 |
Number of HDDs supported | 4 |
DisplayPort version | 1.4 |
DisplayPorts quantity | 1 |
USB 2.0 ports quantity | 2 |
HDMI ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
HDMI version | 2.1 |
Headphone outputs | 3 |
WiFi-AP antenna jack | 2 |
PCI Express x16 slots | 1 |
Number of M.2 (M) slots | 1 |
Battery type | CR2032 |
Battery Technology | Lithium-Manganese Dioxide (LiMnO2) |
Number of battery cells | 1 |
Battery weight | 3 g |
Lithium weight per battery | 0.07 g |
Country of origin | China |
