GIGABYTE B550 AORUS ELITE AX V2 Motherboard - AMD Ryzen 5000 CPUs, 12+2 Phases VRM, up to 4733MHz DDR4, 1xPCIe 4.0 + 1xPCIe 3.0 M.2, Wi-Fi 6E, 2.5GbE LAN, USB 3.2 Gen 2 - Motherboards - Computer Components

€ 142.50

Add to cart

Without TAX: € 114.92
Brand:Gigabyte Model:B550 AORUS ELITE AX V2 Availability:Pre-order 3-7 W. Days Quantity:3 pcs. Warranty:36 Months

Get Credit

Adv. payment:

Period:

99 € per month Estimated monthly payment amount. Click "Get Credit" and fill out the application form to receive an offer from banks.

Warranty period	3 year(s)
Compatible processor series	AMD Ryzen 5000 Series
Supported processor sockets	Socket AM4
Processor Socket	Socket AM4
Processor manufacturer	AMD
Maximum number of SMP processors	1
HDCP	Yes
Parallel processing technology support	Not supported
DirectX version	12.0
Maximum Resolution	5120 x 2880 pixels
PC health monitoring	Voltage
Motherboard form factor	ATX
audio chip	Realtek ALC897
Cooling type	Passive
Audio output channels	7.1 channels
Windows operating systems supported	Windows 10 x64
MOTHERBOARD CHIPSET	AMD B550
Product colour	Black
Motherboard chipset family	AMD
Power source type	ATX
Number of memory slots	4
Memory channels	Dual-channel
Unbuffered memory	Yes
Maximum internal memory	128 GB
Memory slots type	DIMM
Supported memory types	DDR4-SDRAM
Supported memory clock speed (max)	4733 MHz
Maximum internal memory per slot	32 GB
ECC сompatibility	ECC & Non-ECC
Supported memory clock speeds	3466
Depth	244 mm
Height	35 mm
Width	305 mm
Wi-Fi standards	802.11a
Ethernet interface type	2.5 Gigabit Ethernet
Wi-Fi	Yes
Ethernet LAN	Yes
Bluetooth Version	5.3
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX210
LAN controller	Realtek RTL8125
Bluetooth	Yes
USB 2.0 connectors	2
12V power connector	Yes
EPS power connector (8-pin)	Yes
RGB LED pin header	Yes
Number of SATA III connectors	4
TPM connector	Yes
Front panel audio connector	Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
Front panel connector	Yes
CPU fan connector	Yes
Number of chassis fan connectors	3
ATX Power connector (24-pin)	Yes
Number of CPU fan connectors	1
Number of EPS power connectors (8-pin)	1
Number of water pump connectors	4
Number of RGB LED pin headers	5
Desktop Management Interface (DMI) version	2.7
BIOS Type	UEFI AMI
Clear CMOS jumper	Yes
Package depth	270 mm
Package height	80 mm
Package width	335 mm
PACKAGE WEIGHT	1.89 kg
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Screws included	Yes
Antenna included	Yes
Batteries Included	Yes
Supported storage drive interfaces	M.2, SATA III
RAID levels	10
Number of storage drives supported	6
Supported storage drive types	HDD & SSD
Number of HDDs supported	4
Raid Support	Yes
S/PDIF out port	Yes
DisplayPort version	1.4
Ethernet LAN (RJ-45) ports	1
WiFi-AP antenna jack	2
DisplayPorts quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
HDMI ports quantity	1
Microphone in	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Headphone outputs	1
USB 2.0 ports quantity	2
HDMI version	2.1
Line-in	Yes
Number of M.2 (M) slots	2
PCI Express x1 (Gen 3.x) slots	1
PCI Express x16 (Gen 3.x) slots	2
PCI Express x16 (Gen 4.x) slots	1
2nd M.2 largest key size	22110
1st M.2 highest PCI Express generation	4.0
2nd M.2 highest PCI Express generation	3.0
1st M.2 largest key size	22110
Battery Technology	Lithium-Manganese Dioxide (LiMnO2)
Battery type	CR2032
Battery weight	3 g
Number of battery cells	1
Lithium weight per battery	0.07 g
Weight	1.12 kg
Country of origin	China
Warnings	Avoid direct contact with sensitive electronic components.
