Compatible processor series | AMD Ryzen™ 5000 G-Series |
Processor Socket | Socket AM4 |
Processor manufacturer | AMD |
High Dynamic Range (HDR) supported | Yes |
Graphics card family | AMD |
HDCP | Yes |
Maximum Resolution | 5120 x 2880 pixels |
MOTHERBOARD CHIPSET | AMD B550 |
Windows operating systems supported | Windows 11 x64 |
Audio output channels | 7.1 channels |
Power source type | ATX |
PC health monitoring | Water cooling |
Motherboard form factor | Mini-ITX |
Cooling type | Active |
Motherboard chipset family | AMD |
Supported memory clock speeds | 5100 MHz |
Maximum internal memory | 64 GB |
Unbuffered memory | Yes |
Supported memory module capacities | 32GB |
Number of memory slots | 2 |
Supported memory types | DDR4 SO-DIMM |
Memory slots type | DIMM |
Supported memory clock speed (max) | 5300 MHz |
Memory channels | Dual-channel |
Depth | 170 mm |
Width | 170 mm |
Bluetooth | Yes |
Ethernet interface type | Gigabit Ethernet |
Bluetooth Version | 5 |
Ethernet LAN | Yes |
Wi-Fi | Yes |
Number of SATA connectors | 4 |
12V power connector | Yes |
EPS power connector (8-pin) | Yes |
ATX Power connector (24-pin) | Yes |
Front panel audio connector | Yes |
Audio connector | Yes |
USB 2.0 connectors | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Number of M.2 (M) slots | 2 |
Number of chassis fan connectors | 2 |
Front panel connector | Yes |
CPU fan connector | Yes |
Power fan connector | Yes |
TPM connector | Yes |
Number of LED strips supported | 2 |
Desktop Management Interface (DMI) version | 2.7 |
Clear CMOS jumper | Yes |
BIOS Type | UEFI AMI |
Supported storage drive types | SSD |
Raid Support | Yes |
Supported storage drive interfaces | M.2, PCI Express 3.0, PCI Express 4.0, SATA |
RAID levels | 1 |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
Headphone outputs | 3 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
DisplayPorts quantity | 1 |
HDMI ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
PCI Express x16 slots | 1 |
PCI Express x1 slots | 1 |
