GIGABYTE B550M DS3H R2 Motherboard - AMD Ryzen 5000 CPUs, 5+3 Phases VRM, up to 4733MHz DDR4 (O.C.), 1xPCIe 4.0 + 1xPCIe 3.0 M.2, 1GbE LAN, USB 3.2 Gen 1

GIGABYTE B550M DS3H R2 Motherboard - AMD Ryzen 5000 CPUs, 5+3 Phases VRM, up to 4733MHz DDR4 (O.C.), 1xPCIe 4.0 + 1xPCIe 3.0 M.2, 1GbE LAN, USB 3.2 Gen 1
  • GIGABYTE B550M DS3H R2 Motherboard - AMD Ryzen 5000 CPUs, 5+3 Phases VRM, up to 4733MHz DDR4 (O.C.), 1xPCIe 4.0 + 1xPCIe 3.0 M.2, 1GbE LAN, USB 3.2 Gen 1
  • GIGABYTE B550M DS3H R2 Motherboard - AMD Ryzen 5000 CPUs, 5+3 Phases VRM, up to 4733MHz DDR4 (O.C.), 1xPCIe 4.0 + 1xPCIe 3.0 M.2, 1GbE LAN, USB 3.2 Gen 1
  • GIGABYTE B550M DS3H R2 Motherboard - AMD Ryzen 5000 CPUs, 5+3 Phases VRM, up to 4733MHz DDR4 (O.C.), 1xPCIe 4.0 + 1xPCIe 3.0 M.2, 1GbE LAN, USB 3.2 Gen 1
€ 97.00
-+
Add to cart
  • Without TAX: € 79.51
  • Brand:Gigabyte Model:B550M DS3H R2 Availability:Pre-order 3-7 W. Days Quantity:10 pcs. Warranty:24 Months
Get Credit

Adv. payment:

Period:

99 € per month Estimated monthly payment amount. Click "Get Credit" and fill out the application form to receive an offer from banks.
Warranty period 3 year(s)
Processor manufacturer AMD
Compatible processor series AMD Ryzen 3000 Series
Supported processor sockets Socket AM4
Processor Socket Socket AM4
HDCP Yes
Maximum Resolution 5120 x 2880 pixels
Parallel processing technology support Not supported
DirectX version 12.0
MOTHERBOARD CHIPSET AMD B550
Audio output channels 7.1 channels
Windows operating systems supported Windows 11 x64
Cooling type Passive
Motherboard chipset family AMD
PC health monitoring Fan
audio chip Realtek ALC1220-VB
Product colour Dark brown
Motherboard form factor micro ATX
Component for PC
Power source type ATX
Memory channels Dual-channel
Supported memory clock speeds 2400
Supported memory clock speed (max) 4733 MHz
Number of memory slots 4
Maximum internal memory 128 GB
Memory slots type DIMM
ECC сompatibility ECC & Non-ECC
Maximum internal memory per slot 32 GB
Supported memory types DDR4-SDRAM
Unbuffered memory Yes
Height 35 mm
Width 244 mm
Depth 244 mm
Ethernet LAN Yes
Wi-Fi No
LAN controller Realtek RTL8111H
Ethernet interface type Gigabit Ethernet
Number of SATA III connectors 4
EPS power connector (8-pin) Yes
Front panel audio connector Yes
CPU fan connector Yes
TPM connector Yes
ATX Power connector (24-pin) Yes
Front panel connector Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors 2
Number of chassis fan connectors 2
Serial port headers 1
Number of RGB LED pin headers 5
Number of EPS power connectors (8-pin) 1
Number of CPU fan connectors 1
USB 2.0 connectors 1
RGB LED pin header Yes
Clear CMOS jumper Yes
System management BIOS (SMBIOS) version 2.7
Desktop Management Interface (DMI) version 2.7
BIOS memory size 128 Mbit
BIOS Type UEFI AMI
ACPI version 5.0
PACKAGE WEIGHT 947 g
Package width 265 mm
Package depth 265 mm
Package height 54 mm
Bundled software Norton® Internet Security (OEM version) LAN bandwidth management software
Batteries Included Yes
Screws included Yes
RAID levels 1
Number of storage drives supported 6
Supported storage drive interfaces M.2, PCI Express 3.0, PCI Express 4.0, SATA III
Raid Support Yes
Supported storage drive types HDD & SSD
Number of HDDs supported 4
Ethernet LAN (RJ-45) ports 1
HDMI ports quantity 1
PS/2 ports quantity 1
Line-in Yes
USB 2.0 ports quantity 2
Microphone in Yes
HDMI version 2.1
DisplayPorts quantity 1
DisplayPort version 1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4
Headphone outputs 1
PCI Express x1 (Gen 3.x) slots 1
2nd M.2 highest PCI Express generation 3.0
Number of M.2 (M) slots 2
PCI Express x16 (Gen 3.x) slots 1
PCI Express x16 (Gen 4.x) slots 1
1st M.2 highest PCI Express generation 4.0
2nd M.2 largest key size 2280
1st M.2 largest key size 2280
Battery type CR2032
Number of battery cells 1
Lithium weight per battery 0.07 g
Battery weight 3 g
Battery Technology Lithium-Manganese Dioxide (LiMnO2)
Weight 870 g
