Warranty period | 3 year(s) |
Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen 3000 Series |
Supported processor sockets | Socket AM4 |
Processor Socket | Socket AM4 |
HDCP | Yes |
DirectX version | 12.0 |
Maximum Resolution | 5120 x 2880 pixels |
Parallel processing technology support | Not supported |
Component for | PC |
Motherboard form factor | micro ATX |
Windows operating systems supported | Windows 11 x64 |
Motherboard chipset family | AMD |
MOTHERBOARD CHIPSET | AMD B550 |
Cooling type | Passive |
PC health monitoring | Fan |
audio chip | Realtek ALC1220-VB |
Product colour | Dark brown |
Audio output channels | 7.1 channels |
Power source type | ATX |
Supported memory types | DDR4-SDRAM |
Supported memory clock speeds | 2400 |
Memory channels | Dual-channel |
Supported memory clock speed (max) | 3200 MHz |
Maximum internal memory | 128 GB |
ECC сompatibility | ECC & Non-ECC |
Number of memory slots | 4 |
Maximum internal memory per slot | 32 GB |
Memory slots type | DIMM |
Unbuffered memory | Yes |
Depth | 244 mm |
Height | 35 mm |
Width | 244 mm |
Wi-Fi standards | Wi-Fi 5 (802.11ac) |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
LAN controller | Realtek RTL8111H |
Bluetooth Version | 5.3 |
Bluetooth | Yes |
Ethernet LAN | Yes |
WLAN controller model | Realtek RTL8851BE |
Wi-Fi | Yes |
Ethernet interface type | Gigabit Ethernet |
Number of CPU fan connectors | 1 |
ATX Power connector (24-pin) | Yes |
Number of SATA III connectors | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
EPS power connector (8-pin) | Yes |
TPM connector | Yes |
Serial port headers | 1 |
CPU fan connector | Yes |
Number of RGB LED pin headers | 5 |
Front panel connector | Yes |
RGB LED pin header | Yes |
Number of chassis fan connectors | 2 |
Front panel audio connector | Yes |
Number of EPS power connectors (8-pin) | 1 |
USB 2.0 connectors | 1 |
Clear CMOS jumper | Yes |
System management BIOS (SMBIOS) version | 2.7 |
BIOS Type | UEFI AMI |
Desktop Management Interface (DMI) version | 2.7 |
BIOS memory size | 128 Mbit |
ACPI version | 5.0 |
PACKAGE WEIGHT | 1.24 kg |
Package width | 270 mm |
Package depth | 268 mm |
Package height | 68 mm |
Bundled software | Norton® Internet Security (OEM version)
LAN bandwidth management software |
Antenna included | Yes |
Batteries Included | Yes |
Screws included | Yes |
Supported storage drive interfaces | M.2, PCI Express 3.0, PCI Express 4.0, SATA III |
Supported storage drive types | HDD & SSD |
Number of storage drives supported | 6 |
RAID levels | 1 |
Raid Support | Yes |
Number of HDDs supported | 4 |
HDMI ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
USB 2.0 ports quantity | 2 |
DisplayPorts quantity | 1 |
PS/2 ports quantity | 1 |
Line-in | Yes |
Microphone in | Yes |
Headphone outputs | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
HDMI version | 2.1 |
DisplayPort version | 1.4 |
WiFi-AP antenna jack | 2 |
Number of M.2 (M) slots | 2 |
2nd M.2 largest key size | 2280 |
PCI Express x1 (Gen 3.x) slots | 1 |
1st M.2 largest key size | 2280 |
PCI Express x16 (Gen 3.x) slots | 1 |
PCI Express x16 (Gen 4.x) slots | 1 |
2nd M.2 highest PCI Express generation | 3.0 |
1st M.2 highest PCI Express generation | 4.0 |
Battery type | CR2032 |
Number of battery cells | 1 |
Lithium weight per battery | 0.07 g |
Battery Technology | Lithium-Manganese Dioxide (LiMnO2) |
Battery weight | 3 g |
Weight | 1.14 kg |
