Warranty period | 3 year(s) |
Maximum internal memory supported by processor | 128 GB |
Processor Socket | Socket AM4 |
Supported processor sockets | Socket AM4 |
Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen™ 5 |
On-board graphics card | Yes |
Graphics card family | AMD |
HDCP | Yes |
Maximum Resolution | 5120 x 2880 pixels |
Parallel processing technology support | Not supported |
DirectX version | 12.0 |
Cooling type | Active |
Windows operating systems supported | Windows 11 x64 |
MOTHERBOARD CHIPSET | AMD B550 |
PC health monitoring | Fan |
Audio output channels | 7.1 channels |
Power source type | ATX |
Product colour | Bronze |
Motherboard chipset family | AMD |
Motherboard form factor | micro ATX |
Supported memory clock speed (max) | 4733 MHz |
Supported memory types | DDR4-SDRAM |
Memory channels | Dodeca-channel |
Memory slots type | DIMM |
Number of memory slots | 4 |
Supported memory clock speeds | 4133 |
Unbuffered memory | Yes |
Maximum internal memory | 128 GB |
Supported memory module capacities | 12GB |
Height | 35 mm |
Width | 244 mm |
Depth | 244 mm |
Ethernet LAN | Yes |
Wi-Fi | No |
Ethernet interface type | Gigabit Ethernet |
Total number of SATA connectors | 4 |
TPM connector | Yes |
Audio connector | Yes |
CPU fan connector | Yes |
Front panel connector | Yes |
EPS power connector (8-pin) | Yes |
12V power connector | Yes |
USB 2.0 connectors | 1 |
Front panel audio connector | Yes |
Power fan connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
ATX Power connector (24-pin) | Yes |
Number of SATA III connectors | 4 |
Desktop Management Interface (DMI) version | 2.7 |
Clear CMOS jumper | Yes |
BIOS Type | UEFI AMI |
Package depth | 265 mm |
Package height | 54 mm |
Package width | 265 mm |
PACKAGE WEIGHT | 837 g |
Bundled software | Norton® Internet Security (OEM version)
LAN bandwidth management software |
Batteries Included | Yes |
RAID levels | 10 |
Number of HDDs supported | 2 |
Number of storage drives supported | 6 |
Supported storage drive interfaces | M.2, SATA |
Raid Support | Yes |
Supported storage drive types | SSD |
HDMI version | 2.1 |
PS/2 ports quantity | 1 |
Line-in | Yes |
Microphone in | Yes |
Headphone outputs | 1 |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB 2.0 ports quantity | 4 |
DisplayPort version | 1.4 |
Ethernet LAN (RJ-45) ports | 1 |
DisplayPorts quantity | 1 |
Number of M.2 (M) slots | 2 |
PCI Express x1 slots | 1 |
PCI Express x16 slots | 1 |
Battery type | CR2032 |
Number of battery cells | 1 |
Battery Technology | Lithium-Manganese Dioxide (LiMnO2) |
Battery weight | 3 g |
Lithium weight per battery | 0.07 g |
Country of origin | China |
