GIGABYTE B760M D3HP WIFI6 Motherboard - Supports Intel Core 14th Gen CPUs, 4+1+1 Phases Digital VRM, up to 5600MHz DDR5, 2xPCIe 4.0 M.2, Wi-Fi 6, GbE LAN, USB 3.2 Gen1 - Motherboards - Computer Components

€ 130.50

Add to cart

Without TAX: € 105.24
Brand:Gigabyte Model:B760M D3HP WIFI6 1.0 Availability:Pre-order 3-7 W. Days Quantity:10 pcs. Warranty:24 Months

Get Credit

Adv. payment:

Period:

99 € per month Estimated monthly payment amount. Click "Get Credit" and fill out the application form to receive an offer from banks.

Warranty period	3 year(s)
Compatible processor series	Intel Core i3 14th Gen
Supported processor sockets	LGA 1700
Processor Socket	LGA 1700
Processor manufacturer	Intel
Parallel processing technology support	Not supported
Maximum Resolution	4096 x 2304 pixels
HDCP	Yes
DirectX version	12.0
Windows operating systems supported	Windows 10 x64
Component for	PC
Cooling type	Passive
audio chip	Realtek ALC897
PC health monitoring	Voltage
Motherboard form factor	micro ATX
Product colour	Dark brown
Motherboard chipset family	Intel
Power source type	ATX
Audio output channels	7.1 channels
MOTHERBOARD CHIPSET	Intel B760 Express
Memory channels	Dual-channel
Number of memory slots	4
Supported memory types	DDR5-SDRAM
Memory slots type	DIMM
Supported memory clock speed (max)	5600 MHz
Supported memory clock speeds	5200
Maximum internal memory	192 GB
ECC сompatibility	ECC & Non-ECC
Maximum internal memory per slot	48 GB
Unbuffered memory	Yes
Depth	244 mm
Height	35 mm
Width	244 mm
Wi-Fi standards	Wi-Fi 6 (802.11ax)
WLAN controller model	Realtek RTL8851BE
Ethernet LAN	Yes
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Bluetooth Version	5.3
Ethernet interface type	Gigabit Ethernet
Wi-Fi	Yes
Bluetooth	Yes
LAN controller	Realtek RTL8111H
EPS power connector (8-pin)	Yes
TPM connector	Yes
CPU fan connector	Yes
Parallel connector	Yes
RGB LED pin header	Yes
Number of chassis fan connectors	3
Front panel connector	Yes
12V power connector	Yes
Serial port headers	1
ATX Power connector (24-pin)	Yes
USB 2.0 connectors	2
Front panel audio connector	Yes
Number of SATA III connectors	4
Number of EPS power connectors (8-pin)	1
Number of CPU fan connectors	1
Number of RGB LED pin headers	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
S/PDIF out connector	Yes
BIOS memory size	128 Mbit
Clear CMOS jumper	Yes
BIOS Type	UEFI AMI
Desktop Management Interface (DMI) version	2.7
ACPI version	5.0
System management BIOS (SMBIOS) version	2.7
Package depth	265 mm
Package width	265 mm
Package height	54 mm
PACKAGE WEIGHT	1.2 kg
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Antenna included	Yes
Batteries Included	Yes
Screws included	Yes
RAID levels	0
Number of HDDs supported	4
Number of storage drives supported	6
Raid Support	Yes
Supported storage drive interfaces	M.2, PCI Express 4.0, SATA III
Supported storage drive types	HDD & SSD
HDMI ports quantity	1
VGA (D-Sub) ports quantity	1
Line-in	Yes
Headphone outputs	1
Microphone in	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
HDMI version	2.1
PS/2 ports quantity	1
WiFi-AP antenna jack	2
Ethernet LAN (RJ-45) ports	1
DisplayPorts quantity	1
DisplayPort version	1.2
USB 2.0 ports quantity	2
PCI Express x16 (Gen 4.x) slots	1
Number of M.2 (M) slots	2
PCI Express x1 (Gen 3.x) slots	2
1st M.2 largest key size	2280
2nd M.2 largest key size	2280
1st M.2 highest PCI Express generation	4.0
2nd M.2 highest PCI Express generation	4.0
Battery type	CR2032
Battery Technology	Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells	1
Battery weight	3 g
Lithium weight per battery	0.07 g
Weight	1.11 kg
