GIGABYTE B860M EAGLE Motherboard - Intel Core Ultra Series CPUs, 6+1+2+1 Phases VRM, up to 9066MHz DDR5, 1xPCIe 5.0 + 1xPCIe 4.0 M.2, 2.5GbE LAN, USB 3.2 Gen 1

€ 144.50
  • Without TAX: € 118.44
  • Brand:Gigabyte Model:B860M EAGLE Availability:Pre-order 3-7 W. Days Quantity:2 pcs. Warranty:36 Months
Get Credit

Adv. payment:

Period:

99 € per month Estimated monthly payment amount. Click "Get Credit" and fill out the application form to receive an offer from banks.
Warranty period 3 year(s)
Processor Socket LGA 1851 (Socket V1)
Processor manufacturer Intel
Compatible processor series Intel Core Ultra (Series 2)
Supported processor sockets LGA 1851
HDCP Yes
DirectX version 12.0
Parallel processing technology support Not supported
Maximum Resolution 4096 x 2160 pixels
Power source type ATX
Product colour Dark brown
PC health monitoring Voltage
audio chip Realtek ALC897
Motherboard form factor micro ATX
Audio output channels 7.1 channels
Windows operating systems supported Windows 10 x64
Motherboard chipset family Intel
MOTHERBOARD CHIPSET Intel B860
Cooling type Passive
Memory slots type DIMM
Unbuffered memory Yes
Supported memory types DDR5-SDRAM
Supported memory clock speed (max) 9066 MHz
Memory channels Dual-channel
Supported memory clock speeds 6400
Maximum internal memory 128 GB
Number of memory slots 2
ECC сompatibility ECC & Non-ECC
Maximum internal memory per slot 64 GB
Depth 225 mm
Width 244 mm
Height 35 mm
Ethernet LAN Yes
LAN controller Realtek RTL8125
Ethernet interface type 2.5 Gigabit Ethernet
Wi-Fi No
CPU fan connector Yes
USB 2.0 connectors 2
Front panel connector Yes
RGB LED pin header Yes
ATX Power connector (24-pin) Yes
TPM connector Yes
Number of SATA III connectors 4
S/PDIF out connector Yes
Serial port headers 1
Front panel audio connector Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors 2
EPS power connector (8-pin) Yes
Number of chassis fan connectors 2
Number of CPU fan connectors 2
Number of RGB LED pin headers 3
Number of EPS power connectors (8-pin) 1
Number of water pump connectors 2
Clear CMOS jumper Yes
Desktop Management Interface (DMI) version 2.7
BIOS Type UEFI AMI
Package depth 265 mm
Package height 54 mm
Package width 265 mm
Bundled software Norton® Internet Security (OEM version) LAN bandwidth management software
Batteries Included Yes
Screws included Yes
Number of HDDs supported 4
Supported storage drive interfaces M.2, SATA III
RAID levels 0
Supported storage drive types HDD & SSD
Raid Support Yes
Number of storage drives supported 6
HDMI version 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1
HDMI ports quantity 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3
Ethernet LAN (RJ-45) ports 1
DisplayPorts quantity 1
Headphone outputs 1
PS/2 ports quantity 1
DisplayPort version 2.1
Line-in Yes
USB 2.0 ports quantity 3
Microphone in Yes
PCI Express x16 (Gen 4.x) slots 1
PCI Express x16 (Gen 5.x) slots 1
Number of M.2 (M) slots 2
2nd M.2 highest PCI Express generation 4.0
1st M.2 highest PCI Express generation 5.0
1st M.2 largest key size 2280
2nd M.2 largest key size 2280
Battery Technology Lithium-Manganese Dioxide (LiMnO2)
Battery type CR2032
Number of battery cells 1
Battery weight 3 g
Lithium weight per battery 0.07 g
Weight 1.1 kg
Country of origin China
