GIGABYTE B860M GAMING X WIFI6E Motherboard - Intel Core Ultra Series CPUs, 8+1+2+2 Phases VRM, up to 9200MHz DDR5, 1xPCIe 5.0 + 1xPCIe 4.0 M.2, 2.5GbE LAN, WIFI 6E, USB 4 - Motherboards - Computer Components

€ 153.50

Add to cart

Without TAX: € 123.79
Brand:Gigabyte Model:B860M GAMING X WIFI6E Availability:Pre-order 3-7 W. Days Quantity:10 pcs. Warranty:24 Months

Get Credit

Adv. payment:

Period:

99 € per month Estimated monthly payment amount. Click "Get Credit" and fill out the application form to receive an offer from banks.

Warranty period	3 year(s)
Processor manufacturer	Intel
Supported processor sockets	LGA 1851
Compatible processor series	Intel® Core™ Ultra (Series 1)
Processor Socket	LGA 1851 (Socket V1)
DirectX version	12.0
Parallel processing technology support	Not supported
Maximum Resolution	4096 x 2160 pixels
HDCP	Yes
PC health monitoring	Temperature
Motherboard form factor	micro ATX
Audio output channels	7.1 channels
Motherboard chipset family	Intel
audio chip	Realtek ALC897
Windows operating systems supported	Windows 11 x64
MOTHERBOARD CHIPSET	Intel B860
Cooling type	Passive
Power source type	ATX
Product colour	Dark brown
Unbuffered memory	Yes
Memory slots type	DIMM
Supported memory clock speeds	5600
Memory channels	Dual-channel
Maximum internal memory	256 GB
Supported memory types	DDR5-SDRAM
Number of memory slots	4
Supported memory clock speed (max)	9200 MHz
ECC сompatibility	ECC & Non-ECC
Maximum internal memory per slot	64 GB
Height	35 mm
Width	244 mm
Depth	244 mm
Wi-Fi	Yes
Wi-Fi standards	802.11b
Ethernet LAN	Yes
Bluetooth	Yes
Bluetooth Version	5.3
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
LAN controller	Realtek RTL8125
Ethernet interface type	2.5 Gigabit Ethernet
WLAN controller model	Intel Wi-Fi 6E AX211
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
Thunderbolt headers	2
EPS power connector (8-pin)	Yes
TPM connector	Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors	1
Number of chassis fan connectors	2
Number of SATA III connectors	4
USB 2.0 connectors	2
Front panel audio connector	Yes
CPU fan connector	Yes
RGB LED pin header	Yes
Front panel connector	Yes
ATX Power connector (24-pin)	Yes
Number of RGB LED pin headers	4
Number of water pump connectors	2
Number of CPU fan connectors	2
Number of EPS power connectors (8-pin)	1
BIOS Type	UEFI AMI
Desktop Management Interface (DMI) version	2.7
Clear CMOS jumper	Yes
Package height	68 mm
Package depth	268 mm
Package width	270 mm
PACKAGE WEIGHT	1.43 kg
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Antenna included	Yes
Screws included	Yes
Batteries Included	Yes
RAID levels	10
Number of HDDs supported	4
Raid Support	Yes
Supported storage drive interfaces	M.2, SATA III
Number of storage drives supported	6
Supported storage drive types	HDD & SSD
Headphone outputs	1
DisplayPort version	2.1
WiFi-AP antenna jack	2
DisplayPorts quantity	1
HDMI version	2.1
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 2.0 ports quantity	5
USB4 Gen 2x2 ports quantity	1
Microphone in	Yes
Line-in	Yes
PCI Express x16 (Gen 4.x) slots	1
Number of M.2 (M) slots	2
PCI Express x16 (Gen 5.x) slots	1
1st M.2 largest key size	2280
2nd M.2 highest PCI Express generation	4.0
1st M.2 highest PCI Express generation	5.0
2nd M.2 largest key size	25110
Battery Technology	Lithium-Manganese Dioxide (LiMnO2)
Battery weight	3 g
Battery type	CR2032
Number of battery cells	1
Lithium weight per battery	0.07 g
Weight	1.23 kg
Country of origin	China
