Warranty period | 3 year(s) |
Maximum internal memory supported by processor | 64 GB |
Processor manufacturer | Intel |
Compatible processor series | Intel® Core™ i3 |
Processor Socket | LGA 1700 |
Supported processor sockets | LGA 1700 |
HDCP | Yes |
Parallel processing technology support | Not supported |
Maximum Resolution | 4096 x 2304 pixels |
Motherboard form factor | micro ATX |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 10 x64 |
audio chip | Realtek ALC897 |
Product colour | Black |
Cooling type | Active |
MOTHERBOARD CHIPSET | Intel H610 Express |
Power source type | ATX |
PC health monitoring | Temperature |
Motherboard chipset family | Intel |
Memory channels | Dual-channel |
Number of memory slots | 2 |
Supported memory types | DDR4-SDRAM |
Memory slots type | DIMM |
Supported memory clock speeds | 2933 |
Supported memory module capacities | 2GB |
Maximum internal memory | 64 GB |
Unbuffered memory | Yes |
Supported memory clock speed (max) | 3200 MHz |
Width | 230 mm |
Height | 35 mm |
Depth | 215 mm |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
Wi-Fi | No |
12V power connector | Yes |
RGB LED pin header | Yes |
Serial port headers | 1 |
Front panel connector | Yes |
CPU fan connector | Yes |
EPS power connector (8-pin) | Yes |
Front panel audio connector | Yes |
TPM connector | Yes |
USB 2.0 connectors | 2 |
Number of SATA III connectors | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
ATX Power connector (24-pin) | Yes |
Desktop Management Interface (DMI) version | 2.7 |
Clear CMOS jumper | Yes |
BIOS Type | UEFI AMI |
Clear CMOS button | Yes |
Package height | 52 mm |
PACKAGE WEIGHT | 703 g |
Package depth | 235 mm |
Package width | 265 mm |
Bundled software | Norton Internet Security (OEM version)
LAN bandwidth management software |
CABLES INCLUDED | SATA |
Batteries Included | Yes |
Number of HDDs supported | 1 |
Number of storage drives supported | 5 |
Supported storage drive interfaces | M.2, SATA III |
Supported storage drive types | HDD & SSD |
DVI-D ports quantity | 1 |
VGA (D-Sub) ports quantity | 1 |
Microphone in | Yes |
HDMI ports quantity | 1 |
PS/2 ports quantity | 1 |
Headphone outputs | 3 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
USB connector type | USB Type-A |
DisplayPorts quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
USB 2.0 ports quantity | 4 |
PCI Express x1 slots | 1 |
PCI Express x16 slots | 1 |
Number of M.2 (M) slots | 1 |
Battery type | CR2032 |
Battery Technology | Lithium-Manganese Dioxide (LiMnO2) |
Number of battery cells | 1 |
Lithium weight per battery | 0.07 g |
Battery weight | 3 g |
Country of origin | China |
