Warranty period | 3 year(s) |
Supported processor sockets | Socket AM5 |
Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen™ 7 |
Processor Socket | Socket AM5 |
Maximum internal memory supported by processor | 256 GB |
DirectX version | 12.0 |
Motherboard chipset family | AMD |
PC health monitoring | Temperature |
Audio output channels | 7.1 channels |
Motherboard form factor | ATX |
Windows operating systems supported | Windows 11 x64 |
Product colour | Black |
MOTHERBOARD CHIPSET | AMD X870 |
Supported memory module capacities | 64GB |
Supported memory clock speeds | 5200 |
Maximum internal memory | 256 GB |
Supported memory clock speed (max) | 8000 MHz |
Memory slots type | DIMM |
Number of memory slots | 4 |
Supported memory types | DDR5-SDRAM |
Memory channels | Dual-channel |
Depth | 244 mm |
Width | 305 mm |
Height | 35 mm |
Bluetooth | Yes |
Wi-Fi standards | Wi-Fi 7 (802.11be) |
Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
WLAN controller model | MediaTek MT7925 |
Ethernet LAN | Yes |
Wi-Fi | Yes |
Ethernet interface type | 2.5 Gigabit Ethernet |
Bluetooth Version | 5.4 |
ATX Power connector (24-pin) | Yes |
TPM connector | Yes |
USB 3.2 Gen 2x2 connectors | 1 |
EPS power connector (8-pin) | Yes |
Number of SATA III connectors | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
USB 2.0 connectors | 2 |
RGB LED pin header | Yes |
12V power connector | Yes |
Total number of SATA connectors | 4 |
BIOS Type | UEFI AMI |
Clear CMOS button | Yes |
Clear CMOS jumper | Yes |
Desktop Management Interface (DMI) version | 2.7 |
Package depth | 270 mm |
PACKAGE WEIGHT | 1.94 kg |
Package width | 335 mm |
Package height | 80 mm |
Bundled software | Norton® Internet Security (OEM version)
LAN bandwidth management software |
Batteries Included | Yes |
Raid Support | Yes |
RAID levels | 1 |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
Number of HDDs supported | 7 |
Number of storage drives supported | 4 |
DisplayPorts quantity | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
USB 2.0 ports quantity | 4 |
Ethernet LAN (RJ-45) ports | 1 |
S/PDIF out port | Yes |
HDMI ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
Microphone in | Yes |
USB4 Gen 2x2 ports quantity | 2 |
Number of M.2 (M) slots | 3 |
PCI Express x16 (Gen 5.x) slots | 1 |
PCI Express x4 slots | 2 |
Lithium weight per battery | 0.07 g |
Battery Technology | Lithium-Manganese Dioxide (LiMnO2) |
Number of battery cells | 1 |
Battery weight | 3 g |
Battery type | CR2032 |
Country of origin | China |
