Warranty period | 3 year(s) |
Compatible processor series | AMD Ryzen 9000 Series |
Processor Socket | Socket AM5 |
Processor manufacturer | AMD |
Supported processor sockets | Socket AM5 |
HDCP | Yes |
Parallel processing technology support | Not supported |
Maximum Resolution | 4096 x 2160 pixels |
DirectX version | 12.0 |
MOTHERBOARD CHIPSET | AMD X870 |
Motherboard form factor | Micro ITX |
Audio output channels | 7.1 channels |
PC health monitoring | Voltage |
Product colour | White |
Power source type | ATX |
audio chip | Realtek ALC4080 |
Motherboard chipset family | AMD |
Windows operating systems supported | Windows 11 x64 |
Component for | PC |
Maximum internal memory | 128 GB |
Unbuffered memory | Yes |
Supported memory clock speeds | 4400 |
Maximum internal memory per slot | 64 GB |
ECC сompatibility | Non-ECC |
Memory channels | Dual-channel |
Supported memory types | DDR5-SDRAM |
Memory slots type | DIMM |
Number of memory slots | 2 |
Supported memory clock speed (max) | 8400 MHz |
Height | 35 mm |
Width | 170 mm |
Depth | 170 mm |
Bluetooth Version | 5.4 |
WLAN controller model | Realtek RTL8922AE |
LAN controller | Realtek RTL8125 |
Bluetooth | Yes |
Wi-Fi standards | Wi-Fi 4 (802.11n) |
Wi-Fi | Yes |
Ethernet interface type | 2.5 Gigabit Ethernet |
Ethernet LAN | Yes |
Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
Number of chassis fan connectors | 1 |
ATX Power connector (24-pin) | Yes |
Front panel audio connector | Yes |
RGB LED pin header | Yes |
USB 2.0 connectors | 1 |
Number of SATA III connectors | 2 |
CPU fan connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
Number of CPU fan connectors | 2 |
Chassis intrusion connector | Yes |
EPS power connector (8-pin) | Yes |
Number of RGB LED pin headers | 3 |
Number of EPS power connectors (8-pin) | 1 |
Number of water pump connectors | 1 |
Front panel connector | Yes |
Desktop Management Interface (DMI) version | 2.7 |
System management BIOS (SMBIOS) version | 2.7 |
BIOS Type | UEFI AMI |
Clear CMOS jumper | Yes |
BIOS memory size | 256 Mbit |
ACPI version | 5.0 |
PACKAGE WEIGHT | 1.28 kg |
Package width | 235 mm |
Package height | 95 mm |
Package depth | 227 mm |
Bundled software | Norton® Internet Security (OEM version)
LAN bandwidth management software |
Antenna included | Yes |
Screws included | Yes |
Batteries Included | Yes |
Supported storage drive interfaces | M.2, SATA III |
RAID levels | 1 |
Supported storage drive types | HDD & SSD |
Raid Support | Yes |
Number of HDDs supported | 2 |
Number of storage drives supported | 4 |
Line-in | Yes |
WiFi-AP antenna jack | 2 |
DisplayPort version | 1.4 |
Ethernet LAN (RJ-45) ports | 1 |
USB4 Gen 2x2 ports quantity | 1 |
USB 2.0 ports quantity | 2 |
HDMI version | 2.1 |
HDMI ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Headphone outputs | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
Number of M.2 (M) slots | 2 |
PCI Express x16 (Gen 5.x) slots | 1 |
2nd M.2 highest PCI Express generation | 4.0 |
1st M.2 highest PCI Express generation | 5.0 |
1st M.2 largest key size | 2280 |
2nd M.2 largest key size | 2280 |
Battery weight | 3 g |
Number of battery cells | 1 |
Battery type | CR2032 |
Battery Technology | Lithium-Manganese Dioxide (LiMnO2) |
Lithium weight per battery | 0.07 g |
Weight | 1.2 kg |
Country of origin | Taiwan |
