processor | |
processor manufacturer | Intel |
processor socket | LGA 2066 (Socket R4) |
Compatible processors | Intel® Core™ X-Serie |
Maximum number of SMP processors | 1 |
Supported processor slots | LGA 2066 |
Storage | |
Supported memory | DDR4-SDRAM |
Number of memory slots | 8 |
memory type | DIMM |
memory channels | Vierfach-Kanal |
ECC-Kompatibilität | Nicht-ECC |
Supported memory speed | 2133,2400,2666,2800,2933,3000,3200,3300,3333,3400,3466,3600,3733,3800,3866,4000,4133,4266 MHz |
RAM memory maximum | 256 GB |
Eigenschaft | Nebenkosten inklusive |
storage controller | |
Supported storage drives | HDD & SSD |
Supported storage drive interfaces | PCI Express 3.0, SATA |
Maximum supported number of HDD | 8 |
RAID Level | 0, 1, 5, 10 |
graphic | |
Parallel processing technology | 2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX, 3-Way SLI |
Internal I/O ports | |
Number of USB 2.0 interfaces | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) ports | 2 |
SATA III connectors | 8 |
Number of EATX power plugs | 1 |
Number of chassis fan plugs | 2 |
I/O ports on the back | |
Number of USB 2.0 ports | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports | 3 |
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type-C ports | 1 |
Number of Ethernet LAN ports (RJ-45) | 1 |
headphone outputs | 1 |
Optical audio digital output | 1 |
WiFi AP antenna socket | 1 |
network | |
Ethernet interfaces type | 2.5 Gigabit Ethernet |
LAN-Controller | Realtek RTL8125-CG |
WLAN-Standards | Wi-Fi 6 (802.11ax) |
Bluetooth-Version | 5.0 |
features | |
motherboard chipset | Intel® X299 |
audio chip | SupremeFX S1220A |
audio channels | 8.0 Kanäle |
component for | PC |
Motherboardformfaktor | ATX |
Motherboard chipset family | Intel |
cooling | Aktiv |
energy source | ATX |
Number of mounting holes | 9 |
Supports Windows operating systems | Windows 10 x64 |
expansion slots | |
PCI Express x1 (Gen 3.x) connectors | 1 |
PCI Express x16 (Gen 3.x) connectors | 16 |
BIOS | |
BIOS type | UEFI AMI |
BIOS memory size | 128 Mbit |
ACPI-Version | 6.2 |
System management BIOS (SMBIOS) version | 3.2 |
logistic data | |
Goods tariff number (HS) | 84733020 |
weight and dimensions | |
broad | 305 mm |
depth | 244 mm |
scope of delivery | |
Other functions | |
HDD size | 2.5/3.5" |
PCI Express x4 (Gen 3.x) connectors | 1 |
