Warranty period | 3 year(s) |
Processor Socket | Socket AM5 |
Compatible processor series | AMD Ryzen 8000 Series |
Processor manufacturer | AMD |
Supported processor sockets | Socket AM5 |
DirectX version | 12.0 |
HDCP | Yes |
Maximum Resolution | 4096 x 2160 pixels |
PC health monitoring | Water cooling |
Windows operating systems supported | Windows 11 x64 |
Motherboard chipset family | AMD |
Power source type | ATX |
Audio output channels | 7.1 channels |
Motherboard form factor | ATX |
MOTHERBOARD CHIPSET | AMD B850 |
Memory slots type | DIMM |
Supported memory types | DDR5-SDRAM |
Number of memory slots | 4 |
Memory channels | Dual-channel |
Supported memory clock speed (max) | 8200 MHz |
ECC сompatibility | Non-ECC |
Maximum internal memory per slot | 64 GB |
Supported memory clock speeds | 7600 MHz |
Maximum internal memory | 256 GB |
Unbuffered memory | Yes |
Width | 305 mm |
Height | 35 mm |
Depth | 244 mm |
Bluetooth Version | 5.3 |
WLAN controller model | Realtek RTL8852CE |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
Wi-Fi standards | 802.11g |
Wi-Fi | Yes |
Bluetooth | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
RGB LED pin header | Yes |
Total number of SATA connectors | 4 |
Number of CPU fan connectors | 2 |
Number of EPS power connectors (8-pin) | 1 |
12V power connector | Yes |
Number of RGB LED pin headers | 4 |
Number of SATA III connectors | 4 |
USB 2.0 connectors | 2 |
Peripheral (Molex) power connectors (4-pin) | 1 |
Front panel audio connector | Yes |
TPM connector | Yes |
Front panel connector | Yes |
EPS power connector (8-pin) | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
CPU fan connector | Yes |
Reset button | Yes |
ATX Power connector (24-pin) | Yes |
Number of water pump connectors | 2 |
Desktop Management Interface (DMI) version | 2.7 |
Clear CMOS jumper | Yes |
Clear CMOS button | Yes |
BIOS Type | UEFI AMI |
Bundled software | Norton Internet Security (OEM version)LAN bandwidth management software |
Batteries Included | Yes |
Number of HDDs supported | 4 |
Number of storage drives supported | 7 |
Supported storage drive types | HDD & SSD |
RAID levels | 10 |
Raid Support | Yes |
Supported storage drive interfaces | M.2, SATA III |
HDMI version | 2.1 |
PS/2 ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
HDMI ports quantity | 1 |
Number of audio jack connectors | 3 |
DisplayPorts quantity | 1 |
DisplayPort version | 1.4 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
USB 2.0 ports quantity | 4 |
1st M.2 largest key size | 22110 |
3rd M.2 highest PCI Express generation | 4.0 |
2nd M.2 highest PCI Express generation | 4.0 |
2nd M.2 largest key size | 22110 |
3rd M.2 largest key size | 22110 |
1st M.2 highest PCI Express generation | 5.0 |
PCI Express x16 (Gen 3.x) slots | 3 |
Number of M.2 (M) slots | 3 |
PCI Express x16 (Gen 5.x) slots | 1 |
Battery Technology | Lithium-Manganese Dioxide (LiMnO2) |
Number of battery cells | 1 |
Lithium weight per battery | 0.07 g |
Battery type | CR2032 |
Battery weight | 3 g |
