Warranty period | 3 year(s) |
Compatible processor series | AMD Ryzen™ 7 |
Processor manufacturer | AMD |
Supported processor sockets | Socket AM5 |
Maximum internal memory supported by processor | 192 GB |
Maximum number of SMP processors | 1 |
Processor Socket | Socket AM5 |
DirectX version | 12.0 |
HDCP | Yes |
Parallel processing technology support | Not supported |
Product colour | Black |
Motherboard chipset family | AMD |
MOTHERBOARD CHIPSET | AMD X670 |
Windows operating systems supported | Windows 10 Home x64 |
Audio output channels | 7.1 channels |
Motherboard form factor | ATX |
Supported memory clock speeds | 6800 |
Memory channels | Dual-channel |
Maximum internal memory | 192 GB |
ECC сompatibility | Non-ECC |
Supported memory clock speed (max) | 8000 MHz |
Memory slots type | DIMM |
Supported memory types | DDR5-SDRAM |
Number of memory slots | 4 |
Width | 305 mm |
Depth | 269 mm |
Height | 35 mm |
Wi-Fi standards | Wi-Fi 6E (802.11ax) |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Wi-Fi | Yes |
Bluetooth | Yes |
Ethernet LAN | Yes |
WLAN controller model | Intel Wi-Fi 6E AX210 |
Ethernet interface type | 2.5 Gigabit Ethernet |
Bluetooth Version | 5.3 |
USB 2.0 connectors | 2 |
Number of SATA III connectors | 6 |
Total number of SATA connectors | 6 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
CPU fan connector | Yes |
Front panel connector | Yes |
Chassis intrusion connector | Yes |
USB 3.2 Gen 2x2 connectors | 1 |
Audio connector | Yes |
RGB LED pin header | Yes |
Clear CMOS jumper | Yes |
BIOS Type | UEFI AMI |
Desktop Management Interface (DMI) version | 2.7 |
PACKAGE WEIGHT | 3.33 kg |
Package depth | 335 mm |
Package height | 430 mm |
Package width | 400 mm |
CABLES INCLUDED | SATA |
Drivers included | Yes |
Batteries Included | Yes |
Supported storage drive types | HDD & SSD |
RAID levels | 1 |
Number of storage drives supported | 10 |
Supported storage drive interfaces | M.2, SATA II |
Number of HDDs supported | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
HDMI version | 2.0 |
USB 2.0 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
S/PDIF out port | Yes |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
Number of M.2 (M) slots | 4 |
PCI Express x1 (Gen 4.x) slots | 1 |
PCI Express x4 (Gen 2.x) slots | 1 |
Battery type | CR2032 |
Battery Technology | Lithium-Manganese Dioxide (LiMnO2) |
Lithium weight per battery | 0.07 g |
Battery weight | 3 g |
Number of battery cells | 1 |
Country of origin | Taiwan |
