Maximum number of SMP processors | 1 |
Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen™ 5 |
Supported processor sockets | Socket AM4 |
Processor Socket | Socket AM4 |
Maximum Resolution | 4096 x 2160 pixels |
Parallel processing technology support | Not supported |
audio chip | Realtek ALC897 |
Audio output channels | 7.1 channels |
MOTHERBOARD CHIPSET | AMD B450 |
Motherboard form factor | micro ATX |
Motherboard chipset family | AMD |
Power source type | ATX |
Windows operating systems supported | Windows 10 x64 |
Memory slots type | DIMM |
Unbuffered memory | Yes |
Supported memory clock speeds | 2667 |
Maximum internal memory | 64 GB |
Supported memory types | DDR4-SDRAM |
Number of memory slots | 2 |
Memory channels | Dual-channel |
Depth | 236 mm |
Width | 200 mm |
Ethernet LAN | Yes |
Ethernet interface type | 2.5 Gigabit Ethernet |
Wi-Fi | No |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
CPU fan connector | Yes |
Number of SATA III connectors | 4 |
ATX Power connector (24-pin) | Yes |
Front panel audio connector | Yes |
USB 2.0 connectors | 4 |
Chassis intrusion connector | Yes |
Front panel connector | Yes |
TPM connector | Yes |
Serial port headers | 1 |
Parallel connector | Yes |
BIOS Type | UEFI AMI |
Clear CMOS jumper | Yes |
Drivers included | Yes |
CABLES INCLUDED | SATA |
Supported storage drive interfaces | M.2, SATA III |
Supported storage drive types | SSD |
USB 2.0 ports quantity | 2 |
USB connector type | USB Type-A |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
Ethernet LAN (RJ-45) ports | 1 |
Headphone outputs | 1 |
PS/2 ports quantity | 2 |
DVI-D ports quantity | 1 |
Microphone in | Yes |
HDMI version | 1.4 |
HDMI ports quantity | 1 |
PCI Express x16 slots | 1 |
PCI Express x1 (Gen 2.x) slots | 1 |
Quick installation guide | Yes |
