Maximum number of SMP processors | 1 |
Processor Socket | Socket AM4 |
Compatible processor series | 3rd Generation AMD Ryzen™ 9 |
Processor manufacturer | AMD |
Maximum Resolution | 4096 x 2160 pixels |
Parallel processing technology support | Not supported |
Motherboard form factor | micro ATX |
Audio output channels | 7.1 channels |
MOTHERBOARD CHIPSET | AMD B550 |
Motherboard chipset family | AMD |
Number of memory slots | 4 |
Memory slots type | DIMM |
Supported memory types | DDR4-SDRAM |
Supported memory clock speeds | 3466 |
Maximum internal memory | 128 GB |
Unbuffered memory | Yes |
Memory channels | Dual-channel |
Depth | 244 mm |
Width | 244 mm |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
LAN controller | Realtek 8111HN |
Wi-Fi | No |
12V power connector | Yes |
RGB LED pin header | Yes |
Number of chassis fan connectors | 3 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Serial port headers | 1 |
CPU fan connector | Yes |
Chassis intrusion connector | Yes |
TPM connector | Yes |
Number of SATA III connectors | 4 |
Front panel connector | Yes |
Front panel audio connector | Yes |
ATX Power connector (24-pin) | Yes |
USB 2.0 connectors | 2 |
Clear CMOS jumper | Yes |
Drivers included | Yes |
CABLES INCLUDED | SATA |
Supported storage drive types | HDD & SSD |
RAID levels | 1 |
Supported storage drive interfaces | Serial ATA III |
VGA (D-Sub) ports quantity | 1 |
USB 2.0 ports quantity | 2 |
HDMI ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
DisplayPorts quantity | 1 |
HDMI version | 2.1 |
PCI Express x16 (Gen 4.x) slots | 1 |
Number of M.2 (M) slots | 2 |
PCI Express x1 (Gen 3.x) slots | 2 |
