Supported processor sockets | Socket AM5 |
Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen 7 7th Gen |
Processor Socket | Socket AM5 |
Parallel processing technology support | Not supported |
MOTHERBOARD CHIPSET | AMD B650 |
Audio output channels | 7.1 channels |
audio chip | Realtek ALC897 |
PC health monitoring | Fan |
Motherboard chipset family | AMD |
Motherboard form factor | ATX |
Windows operating systems supported | Windows 11 x64 |
Supported memory clock speeds | 5200 |
Maximum internal memory | 192 GB |
Supported memory clock speed (max) | 6000 MHz |
Supported memory types | DDR5-SDRAM |
Number of memory slots | 4 |
Memory types supported by processor | DDR5-SDRAM |
Width | 243.8 mm |
Depth | 304.8 mm |
Bluetooth | Yes |
LAN controller | Realtek RTL8125B |
Wi-Fi standards | Wi-Fi 4 (802.11n) |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
Ethernet LAN | Yes |
Ethernet interface type | 2.5 Gigabit Ethernet |
Bluetooth Version | 5.3 |
Wi-Fi | Yes |
USB 2.0 connectors | 4 |
CPU fan connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
Front panel audio connector | Yes |
Chassis intrusion connector | Yes |
Number of M.2 (M) slots | 2 |
ATX Power connector (24-pin) | Yes |
Front panel connector | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
BIOS Type | UEFI AMI |
Supported storage drive interfaces | M.2, SATA |
RAID levels | 0 |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
Line-in | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
Headphone outputs | 1 |
Microphone in | Yes |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
HDMI version | 2.1 |
PCI Express x16 (Gen 3.x) slots | 4 |
