Maximum internal memory supported by processor | 128 GB |
Processor manufacturer | AMD |
Supported processor sockets | Socket AM5 |
Processor Socket | Socket AM5 |
On-board graphics card | No |
Parallel processing technology support | Not supported |
audio chip | Realtek ALC897 |
Motherboard form factor | micro ATX |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 10 x64 |
Product colour | White |
Motherboard chipset family | AMD |
MOTHERBOARD CHIPSET | AMD B650 |
Supported memory types | DDR5-SDRAM |
Memory channels | Dual-channel |
Unbuffered memory | Yes |
Number of memory slots | 4 |
Supported memory clock speed (max) | 7600 MHz |
Maximum internal memory | 128 GB |
Supported memory clock speeds | 6800 |
ECC сompatibility | Non-ECC |
Width | 243.8 mm |
Depth | 243.8 mm |
Wi-Fi standards | Wi-Fi 4 (802.11n) |
Ethernet LAN | Yes |
Bluetooth Version | 5.3 |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Ethernet interface type | 2.5 Gigabit Ethernet |
Wi-Fi | Yes |
Bluetooth | Yes |
CPU fan connector | Yes |
Front panel audio connector | Yes |
Number of SATA III connectors | 4 |
TPM connector | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
Chassis intrusion connector | Yes |
RGB LED pin header | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
Front panel connector | Yes |
USB 2.0 connectors | 4 |
BIOS Type | UEFI AMI |
CABLES INCLUDED | SATA |
RAID levels | 10 |
Supported storage drive interfaces | M.2, PCI Express |
Supported storage drive types | HDD & SSD |
Raid Support | Yes |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
DisplayPorts quantity | 1 |
DisplayPort version | 1.4 |
HDMI version | 2.1 |
USB 2.0 ports quantity | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
HDMI ports quantity | 1 |
S/PDIF out port | Yes |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
Number of M.2 (M) slots | 2 |
PCI Express x1 slots | 1 |
PCI Express x16 slots | 1 |
Warnings | Avoid contact with liquids to prevent electronic damage. |
