Processor Socket | Socket AM5 |
Maximum internal memory supported by processor | 256 GB |
Supported processor sockets | Socket AM5 |
Compatible processor series | AMD Ryzen 7000 Series |
Processor manufacturer | AMD |
Motherboard form factor | ATX |
audio chip | Realtek ALC897 |
Product colour | Black |
MOTHERBOARD CHIPSET | AMD B850 |
Motherboard chipset family | AMD |
Windows operating systems supported | Windows 11 x64 |
Audio output channels | 7.1 channels |
Supported memory clock speeds | 6400 |
Number of memory slots | 4 |
Supported memory types | DDR5-SDRAM |
Maximum internal memory | 256 GB |
ECC сompatibility | Non-ECC |
Memory channels | Dual-channel |
Supported memory clock speed (max) | 8200 MHz |
Depth | 304.8 mm |
Width | 243.8 mm |
Bluetooth Version | 5.3 |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Wi-Fi | Yes |
Bluetooth | Yes |
Wi-Fi standards | Wi-Fi 6E (802.11ax) |
Ethernet LAN | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
RGB LED pin header | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Number of SATA III connectors | 4 |
USB 2.0 connectors | 4 |
CPU fan connector | Yes |
TPM connector | Yes |
Number of HDDs supported | 4 |
RAID levels | 1 |
Supported storage drive types | HDD & SSD |
Raid Support | Yes |
Supported storage drive interfaces | M.2, SATA III |
Ethernet LAN (RJ-45) ports | 1 |
DisplayPorts quantity | 1 |
DisplayPort version | 1.4 |
HDMI version | 2.1 |
HDMI ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
2nd M.2 largest key size | 2280 |
2nd M.2 highest PCI Express generation | 4.0 |
Number of M.2 (M) slots | 2 |
1st M.2 largest key size | 22110 |
1st M.2 highest PCI Express generation | 5.0 |
