Supported processor sockets | Socket AM5 |
Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen 7 7th Gen |
Processor Socket | Socket AM5 |
Motherboard form factor | ATX |
Audio output channels | 7.1 channels |
Product colour | Black |
MOTHERBOARD CHIPSET | AMD B650 |
audio chip | Realtek ALC4080 |
Motherboard chipset family | AMD |
PC health monitoring | Fan |
Windows operating systems supported | Windows 11 x64 |
Supported memory clock speeds | 5000 |
Maximum internal memory | 128 GB |
Supported memory types | DDR5-SDRAM |
Number of memory slots | 4 |
Depth | 243.8 mm |
Width | 304.8 mm |
Bluetooth | Yes |
LAN controller | Realtek RTL8125B |
Wi-Fi standards | 802.11b |
Bluetooth Version | 5.2 |
Ethernet interface type | 2.5 Gigabit Ethernet |
Wi-Fi | Yes |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Ethernet LAN | Yes |
Number of SATA III connectors | 6 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
USB 2.0 connectors | 4 |
Front panel audio connector | Yes |
ATX Power connector (24-pin) | Yes |
Chassis intrusion connector | Yes |
CPU fan connector | Yes |
Front panel connector | Yes |
Supported storage drive interfaces | M.2, SATA |
Raid Support | Yes |
RAID levels | 10 |
Ethernet LAN (RJ-45) ports | 1 |
S/PDIF out port | Yes |
HDMI version | 2.1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
HDMI ports quantity | 1 |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
Microphone in | Yes |
Headphone outputs | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
USB 2.0 ports quantity | 2 |
PCI Express x16 (Gen 3.x) slots | 1 |
Number of M.2 (M) slots | 3 |
