Supported processor sockets | LGA 1700 |
Processor Socket | LGA 1700 |
Processor manufacturer | Intel |
Compatible processor series | Intel® Pentium® Gold |
Motherboard chipset family | Intel |
audio chip | Realtek ALC897 |
Windows operating systems supported | Windows 11 x64 |
Power source type | ATX |
MOTHERBOARD CHIPSET | Intel B760 |
Audio output channels | 7.1 channels |
Motherboard form factor | micro ATX |
Unbuffered memory | Yes |
Supported memory clock speeds | 6800 |
Maximum internal memory | 192 GB |
Number of memory slots | 4 |
Supported memory types | DDR5-SDRAM |
Depth | 243.8 mm |
Width | 243.8 mm |
LAN controller | Realtek RTL8111H |
Ethernet interface type | Gigabit Ethernet |
Ethernet LAN | Yes |
Wi-Fi | No |
Chassis intrusion connector | Yes |
Front panel connector | Yes |
TPM connector | Yes |
Number of SATA III connectors | 4 |
CPU fan connector | Yes |
Front panel audio connector | Yes |
Number of COM connectors | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
USB 2.0 connectors | 4 |
ATX Power connector (24-pin) | Yes |
Parallel connector | Yes |
RGB LED pin header | Yes |
BIOS Type | UEFI AMI |
Clear CMOS jumper | Yes |
CABLES INCLUDED | SATA |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | SATA III |
Raid Support | Yes |
RAID levels | 1 |
Number of storage drives supported | 6 |
Number of HDDs supported | 4 |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
DisplayPorts quantity | 1 |
HDMI version | 1.4 |
PS/2 ports quantity | 2 |
USB 2.0 ports quantity | 4 |
DisplayPort version | 1.4 |
Line-in | Yes |
VGA (D-Sub) ports quantity | 1 |
Microphone in | Yes |
Headphone outputs | 1 |
PCI Express x16 (Gen 4.x) slots | 1 |
PCI Express x1 (Gen 4.x) slots | 2 |
