Processor Socket | LGA 1700 |
Maximum number of SMP processors | 1 |
Processor manufacturer | Intel |
Compatible processor series | Intel® Core™ i9 |
Supported processor sockets | LGA 1700 |
Parallel processing technology support | Not supported |
Audio output channels | 7.1 channels |
Motherboard form factor | micro ATX |
audio chip | Realtek ALC897 |
Motherboard chipset family | Intel |
MOTHERBOARD CHIPSET | Intel H610 |
Supported memory clock speed (max) | 3200 MHz |
Supported memory types | DDR4-SDRAM |
Memory slots type | DIMM |
Memory channels | Dual-channel |
Supported memory clock speeds | 2133 MHz |
Number of memory slots | 2 |
Maximum internal memory | 64 GB |
Height | 65 mm |
Ethernet LAN | Yes |
Wi-Fi | No |
Ethernet interface type | Gigabit Ethernet |
CPU fan connector | Yes |
Number of SATA III connectors | 4 |
ATX Power connector (24-pin) | Yes |
Front panel audio connector | Yes |
TPM connector | Yes |
USB 2.0 connectors | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
Number of chassis fan connectors | 1 |
12V power connector | Yes |
Clear CMOS jumper | Yes |
BIOS Type | UEFI AMI |
Drivers included | Yes |
CABLES INCLUDED | SATA |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
HDMI version | 2.1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
HDMI ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
USB 2.0 ports quantity | 4 |
VGA (D-Sub) ports quantity | 1 |
Weight | 760 g |
